Description
Panasonic FK SMT Aluminum Electrolytic Capacitors feature a high endurance of up to 2000 hours at +105°C and a temperature range as low as -55°C.
Features & Specs
- Capacitance: 47µF
- Tolerance: ±20%
- Voltage - Rated: 35V
- Lifetime @ Temp.: 2000 Hrs @ 105°C
- Operating Temperature: -55°C ~ 105°C
- Polarization: Polar
- Ratings: AEC-Q200
- Ripple Current @ Low Frequency: 180 mA @ 120 Hz
- Ripple Current @ High Frequency: 240 mA @ 100 kHz
- Impedance: 360mOhms
- Diameter: 0.248" (6.30mm)
- Height - Seated (Max): 0.240" (6.10mm)
- Surface Mount Land Size: 0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type: Surface Mount
- Mfg #: EEE-FK1V470P
Features & Specs
- Capacitance: 47µF
- Tolerance: ±20%
- Voltage - Rated: 35V
- Lifetime @ Temp.: 2000 Hrs @ 105°C
- Operating Temperature: -55°C ~ 105°C
- Polarization: Polar
- Ratings: AEC-Q200
- Ripple Current @ Low Frequency: 180 mA @ 120 Hz
- Ripple Current @ High Frequency: 240 mA @ 100 kHz
- Impedance: 360mOhms
- Diameter: 0.248" (6.30mm)
- Height - Seated (Max): 0.240" (6.10mm)
- Surface Mount Land Size: 0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type: Surface Mount
- Mfg #: EEE-FK1V470P
Documentation
