Description
Canon DP-V2730 Overview
Utilize this DP-V2730 UHD 4K Reference Display from Canon on your next narrative feature set for a high-quality production monitor with both SDI and HDMI connectivity. The DP-V2730 features a 27" 3840 x 2160 TFT LCD screen with 100 cd/m² brightness and 89° viewing angle for high visibility. Four 12G/3G/HD/SD-SDI inputs and one HDMI input allow for expanded video signal compatibility. A multifunctional SDI output can provide both dual- and quad-display arrays in multicamera applications.
Advanced HDR monitoring tools effectively display the differences between user LUTs and help aid in contrast adjustments, among other settings. A USB 3.0 Type-A port on the front panel can be used to upload custom LUTs. Two RJ45 ports, one for LAN and one for GPI connectivity, offer additional device compatibility like daisy chaining multiple displays together. Control over the monitor can be achieved remotely via Web UI software or using the onboard buttons on the front panel.
- Supports IRE, PQ, HLG, and Log signals from multiple manufacturers
- View up to UHD 4K in dual or quad array from both SDI and HDMI signals as well as individual picture profiles or user LUTs
- Link to a computer, tablet, or smartphone via Remote Control Web UI
- The software provides live image viewing, detailed signal information, and direct control over inputs, monitoring tools, and settings
- Built-in four-way SDI input switching with multifunctional SDI output
- LAN connection can daisy-chain multiple Canon display units
- Onboard buttons and joystick control on the front panel
- User-uploaded LUTS
- Waveform and RGB parade
- False color
- Range check
- Pixel value check and chromaticity diagram
- Out of Gamut display
- HDR/SDR comparison
- Histogram
- Frame luminance
- Multi-information view
In the Box
- Canon DP-V2730 UHD 4K Reference Display
- AC Power Cord
Canon DP-V2730 Specs
| Panel Type | TFT LCD |
| Display Size | 27.00" / 68.6 cm |
| Screen Area | 23.5 x 13.2" / 596.7 x 335.7 mm |
| Resolution | 3840 x 2160 |
| Aspect Ratio | 16:9 |
| Viewing Angle | 89° |
| Touchscreen | No |
| Maximum Brightness | 100 cd/m2 (Sustained) 1000 cd/m2 (Peak) |
| Contrast Ratio | 1,000,000:1 |
| HDR Compatibility | Hybrid Log Gamma, Advanced HDR |
| Pixels Per Inch (ppi) | 163 ppi |
| Finish | Anti-Glare / Matte |
| Image Controls | False Color, Histogram, Out-of-Gamut Display, RGB Parade |
| Video I/O | 4 x BNC (12G-SDI) Input 4 x BNC (12G-SDI) Output 1 x HDMI Input 1 x BNC Output |
| HDCP Support | Yes, Version 2.3 |
| Audio I/O | 2 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | 1 x 2 W |
| Power I/O | 1 x IEC Input |
| Other I/O | 1 x RJ45 (GPI) Input 1 x USB-A Input 1 x RJ45 (LAN) Input |
| Media/Memory Card Slot | None |
| Wi-Fi | Yes |
| Video Format | HDMI/SDI (10-Bit 4:2:2) UHD 4K: 60 HDMI/SDI (12-Bit 4:4:4) UHD 4K: 30 |
| Video Standard Compliance | SMPTE 259M/274M/296M/372M/425M/ST-2081/ST-2082 ITU -R BT.709 |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption | 525 W (Maximum) 0.5 W (Standby) |
| Mounting-Hole Pattern | 200 x 100 mm |
| Mounting | None |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 20 to 85% (Non-Condensing) |
| Storage Temperature | -4 to 104°F / -20 to 40°C |
| Storage Humidity | 20 to 85% (Non-Condensing) |
| Dimensions | 25 x 16.8 x 6.2" / 635 x 426 x 158 mm 25 x 17.6 x 8.4" / 635 x 447 x 214 mm, Including Stand |
| Weight | 35.3 lb / 16 kg |
