Description
The CTB9200/8A is a 8-pole 320V/12A female pluggable professional rising Clamp Terminal Block with UL94-V0 flame retardant PA green polarised moulding, tinned phosphor bronze pin/terminal, nickel copper flash brass rising clamp, M3 steel zinc plated captive screw, 5mm pitch. It features anti solder wicking and guided pin alignment. It accepts 0.2 to 2.5mm� (30 to 12AWG) solid and stranded cable.
- >=2.5kV Dielectric strength
- 4kV Impulse withstand voltage
- 0.5Nm Torque
- 1.4mm Recommended PCB hole size
Applications
Industrial
Product details
| Wire Size AWG Max | 12AWG |
| Wire Connection Method | Screw |
| Rated Current | 12A |
| No. of Positions | 8Ways |
| Conductor Area CSA | 2.5mm� |
| Product Range | CTB9200 Series |
| Pitch Spacing | 5mm |
| Wire Size AWG Min | 30AWG |
| Rated Voltage | 320V |
Other details
| Brand | CAMDENBOSS |
| Part Number | CTB9200/8A |
| Quantity | Each |
| Technical Data Sheet EN |  |
