Description
Cambium XV2-23T0A00-US Overview
With long-range internal antennas and an IP67 rating, the XV2-23T Wi-Fi 6 Dual-Band Outdoor Access Point from Cambium is an ideal way for businesses such hospitality, education, and transportation to deliver reliable wireless connectivity. Featuring Wi-Fi 6 (802.11ax) standards, this software-defined access point provides up to 2975 Mb/s transfer speeds over the 2.4 GHz and 5 GHz bands. This access point also supports up to 256 clients and 16 SSIDs to separate access privileges. The PoE compliant Gigabit Ethernet uplink port allows you to transfer power and data to the pole and wall mountable access point using a single cable. You can manage the system using cloud-based platforms such as cnMaestro X and cnMaestro Essentials or the Swift mobile app.
In the Box
- Cambium XV2-23T Wi-Fi 6 Dual-Band Outdoor Access Point
- Pole Mounting Kit
- Wall Mounting Bracket
- Limited Lifetime Warranty
Cambium XV2-23T0A00-US Specs
| Wi-Fi |
Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (2 x 2)
|
| Throughput |
2975 Mb/s Total
5 GHz: 2402 Mb/s 2.4 GHz: 573 Mb/s |
| Inputs/Outputs |
1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Uplink) PoE
|
| Wi-Fi |
Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (2 x 2)
|
| Antenna Gain |
7 to 10 dBi
|
| Supported Protocols |
IPv4
IPv6 RADIUS |
| Antenna Placement |
Internal
|
| Bluetooth |
No
|
| Throughput |
2975 Mb/s Total
5 GHz: 2402 Mb/s 2.4 GHz: 573 Mb/s |
| Inputs/Outputs |
1 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Uplink) PoE
|
| USB Sharing Support |
No
|
| Wireless Security |
WEP, WPA, WPA-PSK, WPA2, WPA2-Enterprise, WPA3
|
| VPN Protocol |
L2TP, PPTP
|
| Lock Slot |
Yes, Kensington
|
| Operation Modes |
Access Point
|
| Supported Clients |
256
|
| Max SSIDs Supported |
16
|
| Mobile App Compatible |
Yes
*As of March, 2023: Check with manufacturer for the most up-to-date compatibility |
| Supported IEEE Standards |
802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, 802.11r, 802.1x, 802.3ad, 802.3af
|
| Power Consumption |
11 W
|
| Operating Temperature |
-8 to 97°F / -40 to 65°C
|
| Storage Temperature |
-40 to 158°F / -40 to 70°C
|
| Operating Humidity |
95%
|
| Mount Options |
Pole, Wall
|
| Dimensions |
11.8 x 7.9 x 3.3" / 300 x 200 x 84 mm
|
| Weight |
2.7 lb / 1220 g
|
| Package Weight |
3.715 lb
|
| Box Dimensions (LxWxH) |
15.1 x 9.5 x 3.8"
|
