Description
BZBGEAR BG-4K-VP44 Overview
This 4x4 UHD 4K Seamless HDMI Matrix Switcher/Video Wall Processor/Multiviewer from BZB Gear is a compact and versatile all-in-one device that integrates seamless matrix switching with a video wall processor with seven different modes and a multiviewer function that can display up to four inputs on the same screen. Equipped with four HDMI inputs and four HDMI outputs, the unit handles resolutions up to 4K60 and has 4:4:4 chroma subsampling.
Capable of embedding audio onto its HDMI outputs or de-embedding it from its HDMI inputs via respective 3.5mm stereo outputs for analog audio and coaxial RCA ports for digital audio. The unit supports Dolby 5.1 and DTS 5.1 and has advanced EDID management to ensure wide compatibility with a multitude of devices. Ethernet cable connectivity and a 3-pin Phoenix block connector provide options for controlling the unit via TCP/IP or RS-232, in addition to its onboard panel buttons. The compact design facilitates easy installation, and an included IR remote provides you with control when the unit is placed slightly out of reach.
- Four HDMI inputs that can be independently routed to the four HDMI outputs
- Seamless switching without delay or picture loss during transitions
- Resolutions up to 4K60 with 4:4:4 chroma subsampling
- Video wall capabilities with up to seven different modes on each display
- Multiview of up to four inputs on the same screen in multiple display modes
- Supports HDMI audio formats, including Dolby-5.1 and DTS 5.1
- Analog audio embedding, extraction, and independent audio switching
- HDCP 2.2 compliant with EDID management.
- Control via panel button, remote, RS-232, and TCP/IP
In the Box
- BZBGEAR 4x4 UHD 4K Seamless HDMI Matrix Switcher / Video Wall Processor / Multiviewer
- IR Remote
- Wide Band IR Receiver Cable
- 12 VDC, 3A Power Adapter
- 3-Pin Phoenix Terminal Plug
-
Limited 3-Year Manufacturer Warranty
Registration Extension: 2-Year
BZBGEAR BG-4K-VP44 Specs
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
UHD 4K at 60
|
| Color Processing |
8-Bit 4:4:4 YUV
|
| Video Inputs |
4x HDMI (2.0) Female
|
| Input Video Format |
HDMI (8-Bit 4:4:4 YUV)
UHD 4K at 30/60 fps 1080p 1080i 720p |
| Audio Inputs |
4x 1/8" / 3.5 mm TRS Stereo Analog Female
|
| Input Audio Format |
LPCM (Linear Pulse-Code Modulation)
|
| Embedded Audio Input |
HDMI
|
| Video Outputs |
4x HDMI (2.0) Female
|
| Output Video Format |
HDMI (8-Bit 4:4:4 YUV)
UHD 4K at 30/60 fps 1080p 1080i 720p |
| Audio Outputs |
4x 1/8" / 3.5 mm TRS Stereo Analog Female
4x RCA 8-Channel S/PDIF Female |
| Output Audio Format |
S/PDIF
Analog |
| Embedded Audio Output |
HDMI
|
| Multiview Output |
4-Way Multiview
|
| Other I/O |
1x RJ45 Control Input/Output
1x Block 3-Pin RS-232 Input/Output 1x 1/8" / 3.5 mm IR Input |
| HDCP Support |
Yes, Version 2.2
Yes, Version 1.4 |
| DTS Compatibility |
DTS
|
| Dolby Compatibility |
Dolby Digital
|
| Wi-Fi |
Yes
|
| Bluetooth |
Yes
|
| Power I/O |
1x Barrel (12 VDC at 3 A) Input
|
| Power Consumption |
Device: 23 W
|
| Operating Temperature |
23 to 104°F / -5 to 40°C
|
| Storage Temperature |
-14 to 140°F / -25 to 60°C
|
| Operating Humidity |
5 to 90% ()
|
| Dimensions |
10.3 x 6.4 x 1.4" / 262 x 163 x 36 mm
|
| Weight |
6 lb / 2.7 kg
|
| Package Weight |
8.38 lb
|
| Box Dimensions (LxWxH) |
19.5 x 12.8 x 3"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
