Description
BZBGear UHD-QVP Overview
Add a matrix switcher to your video wall, event space, or video distribution environment with this 4x2 4K/UHD Quad-View/Multiviewer Switcher/Scaler with USB Capture from BZB Gear. This switching/scaling matrix allows you to connect between up to four HDMI 2.0 sources with up to UHD 4K60 8-bit 4:4:4 resolution to either two individual 4K displays, or you can split up the 4K input signal to up to different HDMI matrix displays in different layouts. The unit also includes a USB 3.0 capture card allowing you to output up to 1080p60 video for recording.
This unit supports HDCP 2.2, EDID management, 18 Gb/s bandwidth on all HDMI ports, and can be controlled via the Ethernet LAN port, via RS-232, via the included IR remote, or by the front-panel buttons. There are RCA analog stereo audio outputs to extract embedded audio from your HDMI inputs for output to a mixer or speaker system.
Key Features
In the Box
- BZBGear 4x2 4K/UHD Quad-View/Multiviewer Switcher/Scaler with USB Capture
- 12V Power Adapter
- IR Remote Control
- IR Receiver Cable
- USB 3.0 Type-A Cable
- Limited 1-Year Warranty
BZBGear UHD-QVP Specs
| Switching Type | IR Remote, Pushbutton |
| Color Processing | 8-Bit 4:4:4 YCbCr |
| Video Input Connectors | 4 x HDMI (HDMI 2.0) Female |
| Input Video Format | HDMI (8-Bit 4:4:4 YCC) DCI 4K: 60 fps UHD 4K: 60 fps 1080p: 60 fps |
| Embedded Audio Input | HDMI: 2-Channel (per Input) |
| Video Output Connectors | 2 x HDMI (HDMI 2.0) Female 1 x HDMI (HDMI 2.0) Female (Preview) 1 x USB Type-A (USB Video) Female |
| Output Video Format | HDMI (4:4:4) UHD 4K: 30/60 fps 1080p: 60 fps |
| Audio Output Connectors | 1 x 2RCA Stereo Analog Female 1 x 1/8" / 3.5 mm TRS Stereo Analog Female |
| Output Audio Format | Analog |
| Embedded Audio Output | HDMI: 2-Channel (per Output) |
| Multiview Output | 4-Way Multiview viaHDMI |
| Other I/O | 1 x DE-9/DB-9 Control, RS-232 Input 1 x RJ45 LAN Input/Output 1 x 3.5 mm IR Input |
| HDCP Support | Version 2.2 |
| OS Compatibility | Windows 7 Windows 8.1 Windows 10 or Later macOS Linux |
| Power Connector | 1 x Barrel (12 VDC at 5 A) Input |
| Power Consumption | Device: 22 W |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 20 to 90% |
| Weight | 4.9 lb / 2.2 kg |
