Description
BZBGEAR EXH-70C4 Overview
Guides & Manuals
BZBGEAR EXH-70C4 Specs
Transmitter Interfaces
| Inputs |
1 x HDMI (HDMI 2.0b)
|
| Embedded Audio Input |
HDMI
|
| Outputs |
1 x RJ45 (HDBaseT)
1 x TOSLINK (S/PDIF) |
| Transmitter Other I/O |
1 x 1/8" / 3.5 mm IR Input
1 x 1/8" / 3.5 mm IR Output 1 x Micro-USB Update 1 x Block 3-Pin RS-232 |
Receiver Interfaces
| Inputs |
1 x RJ45 (HDBaseT)
1 x TOSLINK (S/PDIF) |
| Outputs |
1 x HDMI (HDMI 2.0b)
1 x TOSLINK (S/PDIF) |
| Embedded Audio Output |
HDMI
|
| Receiver Other I/O |
1 x 1/8" / 3.5 mm IR Input
1 x 1/8" / 3.5 mm IR Output 1 x Micro-USB Update 1 x Block 3-Pin RS-232 |
Standards
| HDR Compatibility |
HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
|
| HDCP Support |
Yes, Version 2.2
|
| EDID Support |
Yes
|
Transmission
| Max Transmission Distance |
229.7' / 70 m (via Cat 5e/6)
|
| Video Format |
HDMI (8-Bit)
UHD 4K: 60 fps HDMI (8/10/12-Bit) UHD 4K: 24/30 fps 1080p |
| Audio Format |
S/PDIF
|
| DTS Compatibility |
DTS, DTS-HD Master Audio
|
| Dolby Compatibility |
Dolby Digital, Dolby TrueHD
|
| Supported Cable Types |
Cat 5e/6
|
Power
| Transmitter Power Connector |
1 x Barrel (24 VDC at 1 A) Input
|
| Receiver Power Connector |
1 x Barrel (24 VDC at 1 A) Input
|
| PoE Support |
PoE Proprietary
|
| Transmitter Power Consumption |
(9.6 W)
|
| Receiver Power Consumption |
(9.6 W)
|
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Operating Humidity |
20 to 90% (Non-Condensing)
|
General
| Transmitter Dimensions |
5.5 x 2.6 x 0.7" / 140 x 65 x 18 mm
|
| Receiver Dimensions |
5.5 x 2.6 x 0.7" / 140 x 65 x 18 mm
|
| Transmitter Weight |
8.3 oz / 235 g
|
| Receiver Weight |
8.4 oz / 239 g
|
Packaging Info
| Package Weight |
1.995 lb
|
| Box Dimensions (LxWxH) |
9.8 x 7.8 x 3"
|
