Description
BZBGEAR EXH-70C3 Overview
Guides & Manuals
BZBGEAR EXH-70C3 Specs
Transmitter Interfaces
| Inputs |
1 x HDMI (HDMI 2.0b)
|
| Embedded Audio Input |
HDMI
|
| Outputs |
1 x RJ45
1 x HDMI |
| Transmitter Other I/O |
1 x 1/8" / 3.5 mm IR Input
1 x 1/8" / 3.5 mm IR Output 1 x Micro-USB Update |
Receiver Interfaces
| Inputs |
1 x RJ45
|
| Outputs |
1 x HDMI (HDMI 2.0b)
1 x TOSLINK (S/PDIF) |
| Receiver Other I/O |
1 x 1/8" / 3.5 mm IR Input
1 x 1/8" / 3.5 mm IR Output 1 x Micro-USB Update |
Standards
| HDR Compatibility |
HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
|
| HDCP Support |
Yes, Version 2.2
|
| EDID Support |
Passthrough
|
Transmission
| Max Transmission Distance |
UHD 4K at 60 Hz:
229.7' / 70 m (via Cat 6/6a) 1080p: 229.7' / 70 m (via Cat 6/6a) |
| Video Format |
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC)
UHD 4K: 60 fps |
| Audio Format |
S/PDIF
|
| DTS Compatibility |
DTS, DTS-HD Master Audio
|
| Dolby Compatibility |
Dolby Digital, Dolby TrueHD
|
| Supported Cable Types |
Cat 6/6a
|
Power
| Transmitter Power Connector |
1 x Barrel (12 VDC at 1 A) Input
|
| Receiver Power Connector |
1 x Barrel (12 VDC at 1 A) Input
|
| PoE Support |
PoE Proprietary
|
| Transmitter Power Consumption |
(3.36 W)
|
| Receiver Power Consumption |
(3.36 W)
|
Environmental
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Operating Humidity |
20 to 90% (Non-Condensing)
|
General
| Transmitter Dimensions |
3.5 x 2.7 x 0.7" / 90 x 68 x 18 mm
|
| Receiver Dimensions |
3.5 x 2.7 x 0.7" / 90 x 68 x 18 mm
|
| Transmitter Weight |
5.6 oz / 160 g
|
| Receiver Weight |
5.5 oz / 155 g
|
Packaging Info
| Package Weight |
1.445 lb
|
| Box Dimensions (LxWxH) |
8.65 x 5.6 x 3.05"
|
