Description
BZBGEAR 1x8 8K UHD HDMI2.1 Overview
Engineered for uncompromised signal distribution across high-performance displays, the BZBGEAR 1x8 8K60 HDMI Splitter is a professional video splitter with built-in auto downscaling and audio de-embedding. Supporting video up to 8K60 (4:2:0, 12-bit) and 4K120 (4:4:4, 12-bit), the unit delivers full HDMI 2.1 bandwidth at 48 Gb/s, with rich dynamic range via HDR, HDR10+, Dolby Vision, and HLG support. The splitter is fully HDCP 2.3 compliant, ensuring secure playback from modern 8K and 4K HDR sources, including gaming consoles, media players, and AV processors. Auto downscaling per output and HDR-to-SDR conversion enable seamless integration across mixed-resolution systems without compromising visual fidelity.
Designed for professional AV environments and next-generation home theater setups, the BZBGEAR 1x8 incorporates advanced EDID management, per-port audio de-embedding, and full support for 7.1-channel LPCM, Dolby TrueHD, Dolby Atmos, and DTS-HD Master Audio. With gaming-oriented technologies such as VRR, ALLM, QMS, and QFT, it maintains ultra-smooth, low-latency motion performance. LED indicators for power, input, and output status simplify operation, while the included 12 VDC locking power supply ensures reliability.
- One HDMI 2.1 input supports up to 8K60 or 4K120 video signals
- Eight HDMI 2.1 outputs with per-port auto downscaling
- Audio de-embedding for external sound system routing
- Supports 7.1-channel LPCM, Dolby Atmos, and DTS-HD Master Audio
- HDR, HDR10+, Dolby Vision, and HLG passthrough
- Advanced EDID management with manual control
- HDCP 2.3 and 1.4 compliance for secure content transmission
- LED indicators for power, input, and output monitoring
- Compact chassis with 12 VDC, 2.5A locking power input
- High-bandwidth 48 Gb/s transmission with ESD protection
Items Included
- BZBGEAR 1x8 8K60 HDMI Splitter with Auto Downscaling & Audio De-Embedder
- 12 VDC Multinational Power Supply
- 2 x Mounting Ear
- 4 x Machine Screw
- Limited 5-Year Manufacturer Warranty
Additional Resources
BZBGEAR 1x8 8K UHD HDMI2.1 Specs
| Inputs |
1 x HDMI (HDMI 2.1) Female
|
| Embedded Audio |
HDMI
|
| Outputs |
8x HDMI (HDMI 2.1) Female
|
| Video Format |
HDMI Input (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC)
7680 x 4320 |
| Inputs |
1 x HDMI (HDMI 2.1) Female
|
| Embedded Audio |
HDMI
|
| Outputs |
8x HDMI (HDMI 2.1) Female
|
| Other I/O |
1x USB-C (Firmware)
|
| HDR Support |
Yes: HDR10/HDR10+/Dolby Vision/Hybrid Log Gamma
|
| HDCP Support |
Yes: Version 1.4/2.3
|
| EDID Support |
Manual Control
|
| Max Transmission Distance |
8K:
10' / 3 m UHD 4K at 60 Hz: 26' / 7.9 m UHD 4K at 24 Hz: 39' / 11.9 m 1080p: 49' / 14.9 m |
| Video Format |
HDMI Input (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC)
7680 x 4320 |
| Power I/O |
1x Barrel (12 VDC at 2.5 A) Input
|
| Power Consumption |
Device: 12 VDC at 2.5 A (12.2 W)
|
| ESD Protection |
?8 kV Air-Gap Discharge
?4 kV Contact Discharge |
| Operating Conditions |
32 to 104?F / 0 to 40?C at 20 to 90% Humidity
|
| Storage Conditions |
-4 to 140?F / -20 to 60?C at 20 to 90% Humidity
|
| Material of Construction |
Metal
|
| Dimensions |
9.8 x 4.1 x 1.2" / 250.0 x 104.0 x 30.0 mm
|
| Weight |
1.6 lb / 726 g
|
| Package Weight |
2.575 lb
|
| Box Dimensions (LxWxH) |
12.1 x 9.8 x 2.5"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
