Description
BZBGear BG-UHD-1616M Overview
Add a matrix switcher to your video wall, event space, or video distribution environment with this 16x16 4K UHD 18Gb/s HDMI Video Matrix with EDID/Downscaling/CEC from BZB Gear. The switching/scaling matrix allows you to connect between up to 16 HDMI 2.0b sources with up to UHD 4K60 resolution to 16 individual 4K displays.
This unit supports HDCP 2.2/1.x, EDID management, DVI 1.0, CEC, and ARC and can be controlled via IR remote as well as via RS-232 or IP control over a LAN. There are also 16 coax audio outputs to extract embedded audio from your HDMI inputs for output to a mixer or speaker system. Embedded audio support includes Dolby and DTS digital formats and the HDMI ports support HDR, HDR+, Dolby Vision, and HLG video formats.
In the Box
- BZBGear 16x16 4K UHD 18Gb/s HDMI Video Matrix with EDID/Downscaling/CEC
- Power Adapter
- IR Remote Control
- RS-232 Serial Cable (4.9')
- 2 x Mounting Ear
BZBGear BG-UHD-1616M Specs
| Switching Type | IR Remote, Pushbutton, Software |
| Video Inputs | 16 x HDMI (HDMI 2.0b) Female |
| Input Video Format | HDMI (4:4:4/4:2:2/4:2:0 RGB, YCC) UHD 4K up to 60 fps 1080p up to 60 fps 1080i up to 60 fps |
| Input Audio Format | Analog |
| Embedded Audio Input | HDMI: 2-Channel (per Input) |
| Video Outputs | 16 x HDMI (HDMI 2.0b) Female |
| Output Video Format | HDMI (4:4:4/4:2:2/4:2:0 RGB, YCC) UHD 4K up to 60 fps 1080p up to 60 fps 1080i up to 60 fps |
| Audio Outputs | 16 x RCA Stereo Analog Female |
| Output Audio Format | Analog LPCM (Linear Pulse-Code Modulation) |
| Embedded Audio Output | HDMI: 2-Channel (per Output) |
| Other I/O | 1 x DE-9/DB-9 RS-232 Input/Output 1 x RJ45 LAN Input/Output |
| HDCP Support | Version 2.2 |
| HDR Compatibility | HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma |
| DTS Compatibility | DTS, DTS-HD Master Audio, DTS:X |
| Dolby Compatibility | Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD |
| Wi-Fi | None |
| Bluetooth | None |
| Power I/O | 1 x Barrel (24 VDC at 3.7 A) Input |
| Power Consumption | Power Supply: 100 to 240 VAC (76.8 W) |
| Operating Temperature | 22 to 77°F / -10 to 45°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 20 to 90% |
| Rack Form Factor | 1 RU |
| Dimensions | 17.3 x 7.9 x 1.7" / 440 x 200 x 44 mm |
| Weight | 109.3 oz / 3.1 kg |
| Package Weight | 10.345 lb |
| Box Dimensions (LxWxH) | 20.9 x 14.5 x 3.6" |
