Description
BZBGEAR 4KSH Overview
- 1Description
- 2Clear Images
- 3Audio
- 4HDMI Output & SDI Loop Output
- 5Status LEDs
- 6Durable Metal Enclosure
Expand your video output and display possibilities with the 12G/6G/3G/HD-SDI to HDMI 2.0 Converter with Audio Extraction from BZBGear. The converter enables you to link SDI devices, such as cameras or computers to pro-style HDMI monitors or recorders. It features one 12G/6G/3G/HD-SDI input, one 12G/6G/3G/HD-SDI loop output, and one HDMI 2.0 output. It supports input and output signals up to UHD 4K60 with RGB or YCC 4:2:2 deep color.
The converter allows you to extract analog audio from your transmission using the 3.5mm audio output jack. It also ensures lossless transmission over longer distances. Its rugged metal enclosure features built-in mounting ears for mounting the compact device on your console, wall, or rig.
In the Box
- BZBGEAR 12G/6G/3G/HD-SDI to HDMI 2.0 Converter with Audio Extraction
- Power Adapter
- Rackmount Ears Set
- Limited 3-Year Manufacturer Warranty
Guides & Manuals
- Description
- Clear Images
- Audio
- HDMI Output & SDI Loop Output
- Status LEDs
- Durable Metal Enclosure
BZBGEAR 4KSH Specs
| Video Inputs |
1 x BNC (12G-SDI) Female
|
| Audio Inputs |
No
|
| Video Outputs |
1 x BNC (12G-SDI) Female (Loop Output)
1 x HDMI (HDMI 2.0) Female |
| Audio Outputs |
1 x 1/8" / 3.5 mm TRS Analog Female
|
| Expansion Slots |
No
|
| Input Video Format |
SDI (4:2:2 YCC)
UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 480i / 525 lines at 59.94 fps 576i / 625 lines at 50 fps |
| Output Video Format |
HDMI (4:2:2 YCC)
UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps DCI 2K at 23.98/24/25/29.97/30/50/59.94/60 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080PsF at 25/29.97/30 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps 480i / 525 lines at 59.94 fps 576i / 625 lines at 50 fps |
| Embedded Audio |
HDMI/SDI
|
| Video Standard Compliance |
SMPTE 259M/274M/292M/296M/424M/ST-2081/ST-2082
|
| HDR Compatibility |
Not Specified by Manufacturer
|
| Power I/O |
1 x Micro-USB (5 VDC at 1 A) Input
|
| Power Consumption |
Device: 2.5 W
|
| Operating Temperature |
32 to 72°F / 0 to 40°C
|
| Operating Humidity |
20 to 90% (Non-Condensing)
|
| Certifications |
CE, FCC, RoHS
*as per Manufacturer |
| Dimensions |
3.6 x 1.8 x 0.9" / 92 x 45 x 23 mm
|
| Weight |
6.2 oz / 175 g
|
| Package Weight |
0.615 lb
|
| Box Dimensions (LxWxH) |
8.5 x 5.6 x 2.8"
|
