Description
The 282836-7 is a 7-position 1 row 5mm PCB mount Terminal Block with vertical through hole orientation and side wire entry angle. It has tin-plated brass contacts, nickel-plated M3 brass screws in a polyamide 6.6 GF green housing and Interlocking system, screw wire connection method and accepts 30AWG to 16AWG wires.
- End-to-end stackable with interlock and without loss of centreline spacing
- Green colour
- Polyamide 6.6 - GF material
- Receptacle style
- Side wire entry angle
- Without stacked levels
- Brass contact
- Tin plating
- -40 to +105°C Temperature range
- M3 Screw size
- UL94V-0 Flammability rating
Commercial, Industrial
Other details
| Brand | BUCHANAN - TE CONNECTIVITY |
| Part Number | 282836-7 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Application Note EN | |
| 3D Product Image EN | |
| Manufacturer Catalogue EN | |
| Drawing EN | |
| Operating Instructions EN | |
