Description
The HEDS-5540#A02 is a quick assembly Three Channel Optical Encoder, each encoder contains a lensed LED source, an integrated circuit with detectors and output circuitry and a code wheel which rotates between the emitter and detector IC. It has a third channel index output in addition to the two channel quadrature. This index output is a 90 electrical degree, high true index pulse which is generated once for each full rotation of the code wheel and it utilizes metal code wheels and features external mounting ears.
- Three channel quadrature output with optional index pulse
- Quick and easy assembly
- No signal adjustment required
- Resolutions up to 1024 counts per revolution
- TTL compatible
- Silicone rubber - Semitransparent-ESD protective material
- 500 CPR
Industrial, Automation & Process Control
Warnings Normal handling precautions should be taken to avoid static discharge.Other details
| Brand | BROADCOM |
| Part Number | HEDS-5540#A02 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
