Product details
Inductance Tolerance |
� 30% |
RMS Current (Irms) |
600mA |
Saturation Current (Isat) |
620mA |
Power Inductor Case |
3.5mm x 3.3mm x 2.8mm |
Inductance |
22�H |
Inductor Construction |
Shielded |
Product Range |
SRU3028A Series |
DC Resistance Max |
0.335ohm |
Packaging |
Cut Tape |
Other details
Brand |
BOURNS |
Part Number |
SRU3028A-220Y |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
3D Product Image EN |
|
