The SRU1063A-6R8Y from Bourns is a SRU1063A series SMD shielded power inductor. It is typically used in applications such as driver assistant, infotainment, lighting DC to DC converters, power supplies.
- Automotive grade AEC-Q200 qualified
- Inductance is 6.8µH at 100KHz/0.1V
- Tolerance is ±30%
- DCR (DC resistance of inductor) is 0.0145ohm
- RMS current (Irms) is 5.2A
- Saturation current (Isat) is 5.2A
- Ferrite core, enamelled copper wire and Sn terminal finish
- Operating temperature range from -40°C to 125°C
- Dimension is 10mm x 10mm x 6.5mm
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
BOURNS |
| Part Number |
SRU1063A-6R8Y |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| 3D Product Image EN |
|
| Enhanced Product Overview EN |
|
