This is a Power Inductor (SMD), 180 µH, 550 mA, 260 mA, SRR4828A Series, 4.8mm x 4.8mm x 2.8mm, Shielded product from BOURNS with the model number SRR4828A-181M
Product details
| Inductance |
180µH |
| RMS Current (Irms) |
550mA |
| Saturation Current (Isat) |
260mA |
| Product Range |
SRR4828A Series |
| Power Inductor Case |
4.8mm x 4.8mm x 2.8mm |
| Inductor Construction |
Shielded |
| DC Resistance Max |
1.08ohm |
| Inductance Tolerance |
± 20% |
| Packaging |
Cut Tape |
Other details
| Brand |
BOURNS |
| Part Number |
SRR4828A-181M |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
