This is a Power Inductor (SMD), 120 µH, 470 mA, Shielded, 280 mA, SRR4028 Series, 4.8mm x 4.8mm x 2.8mm product from BOURNS with the model number SRR4028-121Y
Product details
| Inductance |
120µH |
| RMS Current (Irms) |
470mA |
| Inductor Construction |
Shielded |
| Saturation Current (Isat) |
280mA |
| Product Range |
SRR4028 Series |
| Power Inductor Case |
4.8mm x 4.8mm x 2.8mm |
| DC Resistance Max |
0.7ohm |
| Inductance Tolerance |
± 30% |
| RoHS Phthalates Compliant |
To Be Advised |
Other details
| Brand |
BOURNS |
| Part Number |
SRR4028-121Y |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
