Product details
Inductance Tolerance |
± 20% |
RMS Current (Irms) |
4.2A |
Saturation Current (Isat) |
3.9A |
Power Inductor Case |
12.5mm x 12.5mm x 6mm |
Inductance |
18µH |
Inductor Construction |
Shielded |
Product Range |
SRR1260A Series |
DC Resistance Max |
0.036ohm |
Packaging |
Cut Tape |
Other details
Brand |
BOURNS |
Part Number |
SRR1260A-180M |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
3D Product Image EN |
|
