| ₹ 112.63 includes GST and import duties. | |
| B2B customers can avail ₹ 17.18 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Power Inductor (SMD), 470 µH, 290 mA, 340 mA, SRR0745A Series, 7.3mm x 7.3mm x 4.5mm, Shielded product from BOURNS with the model number SRR0745A-471M
Product details
| Inductance | 470µH |
| RMS Current (Irms) | 290mA |
| Saturation Current (Isat) | 340mA |
| Product Range | SRR0745A Series |
| Power Inductor Case | 7.3mm x 7.3mm x 4.5mm |
| Inductor Construction | Shielded |
| DC Resistance Max | 2.2ohm |
| Inductance Tolerance | ± 20% |
| Packaging | Tape & Reel |
Other details
| Brand | BOURNS |
| Part Number | SRR0745A-471M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 110.38 |
| 3-5 | ₹ 109.25 |
| 5-10 | ₹ 107.0 |
| 10+ | ₹ 104.75 |
Bulk discount will be automatically applied during checkout based on quantity.
