Product details
Inductance Tolerance |
� 20% |
RMS Current (Irms) |
2.1A |
Saturation Current (Isat) |
1.85A |
Power Inductor Case |
7.3mm x 7.3mm x 3.5mm |
Inductance |
10�H |
Inductor Construction |
Shielded |
Product Range |
SRR0735A Series |
DC Resistance Max |
0.072ohm |
Packaging |
Cut Tape |
Other details
Brand |
BOURNS |
Part Number |
SRR0735A-100M |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
3D Product Image EN |
|
