Description
This is a Power Inductor (SMD), 2.2 µH, 12 A, 27 A, SRP1038A Series, 11mm x 10mm x 3.8mm, Shielded product from BOURNS with the model number SRP1038A-2R2M
Product details
| Inductance | 2.2µH |
| RMS Current (Irms) | 12A |
| Saturation Current (Isat) | 27A |
| Product Range | SRP1038A Series |
| Power Inductor Case | 11mm x 10mm x 3.8mm |
| Inductor Construction | Shielded |
| DC Resistance Max | 0.007ohm |
| Inductance Tolerance | ± 20% |
| Packaging | Cut Tape |
Other details
| Brand | BOURNS |
| Part Number | SRP1038A-2R2M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
| Product Change Notice EN | |
