Description
This is a Surface Mount Power Inductor, SRN8040 Series, 3.6 �H, 4.9 A, 5.3 A, Shielded, 0.022 ohm product from BOURNS with the model number SRN8040-3R6Y
Product details
Inductance Tolerance | � 30% |
RMS Current (Irms) | 4.9A |
Saturation Current (Isat) | 5.3A |
Power Inductor Case | 8mm x 8mm x 4mm |
Inductance | 3.6�H |
Inductor Construction | Shielded |
Product Range | SRN8040 Series |
DC Resistance Max | 0.022ohm |
Packaging | Cut Tape |
Other details
Brand | BOURNS |
Part Number | SRN8040-3R6Y |
Quantity | Each (Supplied on Cut Tape) |
Technical Data Sheet EN | |
Technical Data Sheet EN | |
3D Product Image EN | |
Product Change Notice EN |
