Description
This is a Surface Mount Power Inductor, SRN5040 Series, 6.8 µH, 2.3 A, 2.6 A, Semishielded, 0.059 ohm product from BOURNS with the model number SRN5040-6R8M
Product details
| Product Range | SRN5040 Series |
| Inductance | 6.8µH |
| RMS Current (Irms) | 2.3A |
| Saturation Current (Isat) | 2.6A |
| Inductor Construction | Semishielded |
| DC Resistance Max | 0.059ohm |
| Power Inductor Case | 5mm x 5mm x 4mm |
| Inductance Tolerance | ± 20% |
| Packaging | Cut Tape |
Other details
| Brand | BOURNS |
| Part Number | SRN5040-6R8M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
