This is a Power Inductor (SMD), 47 µH, 900 mA, 1.1 A, SRN5040 Series, 5mm x 5mm x 4mm, Semishielded product from BOURNS with the model number SRN5040-470M
Product details
| Inductance |
47µH |
| RMS Current (Irms) |
900mA |
| Saturation Current (Isat) |
1.1A |
| Product Range |
SRN5040 Series |
| Power Inductor Case |
5mm x 5mm x 4mm |
| Inductor Construction |
Semishielded |
| DC Resistance Max |
0.324ohm |
| Inductance Tolerance |
± 20% |
| Packaging |
Cut Tape |
Other details
| Brand |
BOURNS |
| Part Number |
SRN5040-470M |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
