Product details
DC Resistance Max - Parallel |
0.0101ohm |
Saturation Current - Parallel |
12.7A |
Product Range |
SRF1260A Series |
Coupled Inductor Case |
12.5mm x 12.5mm x 6mm |
Inductance, Parallel |
3.3µH |
Packaging |
Cut Tape |
RMS Current - Parallel |
9.26A |
Other details
Brand |
BOURNS |
Part Number |
SRF1260A-3R3Y |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
3D Product Image EN |
|
