Product details
Inductance Tolerance |
± 10% |
RMS Current (Irms) |
2.2A |
Saturation Current (Isat) |
3A |
Power Inductor Case |
22mm x 15mm x 7mm |
Inductance |
100µH |
Inductor Construction |
Unshielded |
Product Range |
SDR2207 Series |
DC Resistance Max |
0.168ohm |
Packaging |
Cut Tape |
Other details
Brand |
BOURNS |
Part Number |
SDR2207-101KL |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
3D Product Image EN |
|
