Description
This is a Surface Mount Power Inductor, SDR1006 Series, 4.7 mH, 100 mA, 240 mA, Unshielded, 18 ohm product from BOURNS with the model number SDR1006-472KL
Product details
| Product Range | SDR1006 Series |
| Inductance | 4.7mH |
| RMS Current (Irms) | 100mA |
| Saturation Current (Isat) | 240mA |
| Inductor Construction | Unshielded |
| DC Resistance Max | 18ohm |
| Power Inductor Case | 9.8mm x 9.8mm x 5.8mm |
| Inductance Tolerance | ± 10% |
| Packaging | Cut Tape |
Other details
| Brand | BOURNS |
| Part Number | SDR1006-472KL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
