Description
This is a Power Inductor (SMD), 180 µH, 510 mA, Unshielded, 800 mA, SDR0805 Series, 7.8mm x 7.8mm x 5.3mm product from BOURNS with the model number SDR0805-181KL
Product details
| Inductance | 180µH |
| RMS Current (Irms) | 510mA |
| Inductor Construction | Unshielded |
| Saturation Current (Isat) | 800mA |
| Product Range | SDR0805 Series |
| Power Inductor Case | 7.8mm x 7.8mm x 5.3mm |
| DC Resistance Max | 0.77ohm |
| Inductance Tolerance | ± 10% |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BOURNS |
| Part Number | SDR0805-181KL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
