This is a Power Inductor (SMD), 470 µH, 210 mA, 300 mA, SDR0604 Series, 5.8mm x 5.8mm x 4.8mm, Unshielded product from BOURNS with the model number SDR0604-471KL
Product details
| Inductance |
470µH |
| RMS Current (Irms) |
210mA |
| Saturation Current (Isat) |
300mA |
| Product Range |
SDR0604 Series |
| Power Inductor Case |
5.8mm x 5.8mm x 4.8mm |
| Inductor Construction |
Unshielded |
| DC Resistance Max |
3.3ohm |
| Inductance Tolerance |
± 10% |
| Packaging |
Cut Tape |
Other details
| Brand |
BOURNS |
| Part Number |
SDR0604-471KL |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| 3D Product Image EN |
|
