This is a Surface Mount Power Inductor, SDR0503 Series, 22 µH, 900 mA, 1.06 A, Unshielded, 0.28 ohm product from BOURNS with the model number SDR0503-220ML
Product details
| Product Range |
SDR0503 Series |
| Inductance |
22µH |
| RMS Current (Irms) |
900mA |
| Saturation Current (Isat) |
1.06A |
| Inductor Construction |
Unshielded |
| DC Resistance Max |
0.28ohm |
| Power Inductor Case |
5mm x 4.8mm x 3mm |
| Inductance Tolerance |
± 20% |
| Packaging |
Cut Tape |
Other details
| Brand |
BOURNS |
| Part Number |
SDR0503-220ML |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
