Description
This is a Power Inductor (SMD), AEC-Q200, 22 µH, 30 A, 6.8 A, PQ2614BLA Series, 27.9mm x 19.8mm x 16mm product from BOURNS with the model number PQ2614BLA-220K
Product details
| Inductance | 22µH |
| RMS Current (Irms) | 30A |
| Saturation Current (Isat) | 6.8A |
| Product Range | PQ2614BLA Series |
| Power Inductor Case | 27.9mm x 19.8mm x 16mm |
| Inductor Construction | Shielded |
| DC Resistance Max | 0.0016ohm |
| Inductance Tolerance | ± 10% |
| Packaging | Each |
Other details
| Brand | BOURNS |
| Part Number | PQ2614BLA-220K |
| Quantity | Each |
| Technical Data Sheet EN |  |
