The 4609M-101-103LF is a Bussed Resistor Network features that marking on contrasting background for permanent identification and recommended for rosin flux and solvent clean or no clean flux processes. This 4600M series thick film conformal medium profile SIP comes with an epoxy resin body. The terminal centerline to centerline measurements made at point of emergence of the lead from the body.
- Bussed electrical version
- Medium profile offers increased power handling
- 10000MR Minimum insulation resistance
- 200VRMS Dielectric withstanding voltage
- UL94V-0 Flammability rating
- -55 to 125°C Operating temperature range
Applications
Aerospace, Defence, Military
Product details
| Resistance |
10kohm |
| Product Range |
4600M Series |
| No. of Elements |
8Elements |
| Network Circuit Type |
Bussed |
| Resistor Case Style |
SIP |
| No. of Pins |
9Pins |
| Voltage Rating |
100V |
| Power Rating per Element |
250mW |
| Resistance Tolerance |
± 2% |
| Temperature Coefficient |
± 100ppm/°C |
| Automotive Qualification Standard |
- |
| RoHS Phthalates Compliant |
To Be Advised |
Other details
| Brand |
BOURNS |
| Part Number |
4609M-101-103LF |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
