Description
The 4116R-1-103LF is a thick film Isolated Resistor Network with superior package integrity and compatible with automatic insertion equipment, DIP package of Novolac epoxy body material, 8 isolated resistors in a circuit. Bourns® resistor networks help space-sensitive applications by minimizing space, reducing costs, increasing board yields and reliability by reducing component count.
- 10000MR Insulation resistance
- 200Vrms Dielectric withstanding voltage
- UL94V-0 Flammability
Applications
Computers & Computer Peripherals, Communications & Networking
Product details
| Resistance | 10kohm |
| Resistor Case Style | DIP |
| Voltage Rating | 100V |
| No. of Pins | 16Pins |
| Resistance Tolerance | ± 2% |
| Product Range | 4116R Series |
| Automotive Qualification Standard | - |
| Power Rating per Element | 250mW |
| Temperature Coefficient | ± 100ppm/°C |
| Network Circuit Type | Isolated |
| No. of Elements | 8Elements |
Other details
| Brand | BOURNS |
| Part Number | 4116R-1-103LF |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 298.74 |
| 3-5 | ₹ 295.69 |
| 5-10 | ₹ 289.6 |
| 10+ | ₹ 283.5 |
Bulk discount will be automatically applied during checkout based on quantity.
