Description
BirdDog KBD PTZ Controller Overview
Control your PTZ multicamera setup and monitor up to four cameras simultaneously with the KBD PTZ Controller with Integrated Screen from BirdDog. Built with ocean-bound plastics and recyclable aircraft-grade aluminum, the KDP boasts a rugged, ergonomic design with a large 1280 x 720 display to allow you to quickly pair and switch cameras with a single keystroke.
The new Effortless Camera Settings Sync function enables you to easily copy settings from one X-series device to another, and the integrated tally borders facilitate live switching with optional TriCaster or vMix platforms. The KDP offers NDI|HX2 and NDI|HX3 support as well as VISCA-IP, ONVIF, RS-232, and RS-422 for smooth workflow versatility. Balancing power, operational comfort, and eco-friendly innovation, the KDP is the ideal companion for studio production, live events, and mobile program acquisition applications.
Items Included
- BirdDog KBD PTZ Controller with Integrated Screen
- Limited 5-Year Manufacturer Warranty
Additional Resources
No additional resources available
BirdDog KBD PTZ Controller Specs
| Number of Supported Cameras |
255 Channels via IP
|
| Control I/O |
1x D-Sub 9-Pin (RS-232) Input/Output
1x Phoenix (RS-422) Input/Output 1x RJ45 (IP Control, LAN) Input/Output |
| Controls |
1x 3-Axis, Pan/Tilt, Programmable, Multifunction, Auto-Focus, Manual-Focus, Camera Movement Speed, Focus Speed, White Balance Joystick
Focus, Auto-Focus, Manual-Focus, Gain, Camera Selection, Preset Selection, Menu Buttons |
| Touchscreen |
No
|
| PoE Support |
PoE 802.3af
|
| Power Consumption |
?5 W
|
| Security Lock Support |
No
|
| Number of Supported Cameras |
255 Channels via IP
|
| Supported Control Protocols |
IP
NDI NDI|HX2 NDI|HX3 ONVIF Pelco-D Pelco-P RS-232 RS-422 VISCA |
| IP Streaming |
NDIHX, ONVIF: UHD 4K
|
| Control I/O |
1x D-Sub 9-Pin (RS-232) Input/Output
1x Phoenix (RS-422) Input/Output 1x RJ45 (IP Control, LAN) Input/Output |
| Other I/O |
1x USB-A Input/Output
|
| Controls |
1x 3-Axis, Pan/Tilt, Programmable, Multifunction, Auto-Focus, Manual-Focus, Camera Movement Speed, Focus Speed, White Balance Joystick
Focus, Auto-Focus, Manual-Focus, Gain, Camera Selection, Preset Selection, Menu Buttons |
| Presets |
255 via IP, RS-232, VISCA, Pelco-P, Pelco-D
|
| Native Resolution |
1280 x 720
|
| Touchscreen |
No
|
| PoE Support |
PoE 802.3af
|
| Power Connectors |
1x Barrel / Coaxial
|
| Power Consumption |
?5 W
|
| Input Power |
12 VDC
|
| Operating Conditions |
14 to 130°F / -10 to 54°C at 20 to 80% Humidity
|
| Storage Conditions |
14 to 130°F / -10 to 54°C at 0 to 90% Humidity
|
| Security Lock Support |
No
|
| Dimensions |
14.8 x 7 x 4.6" / 377 x 177 x 118 mm
|
| Package Weight |
7.025 lb
|
| Box Dimensions (LxWxH) |
16.2 x 8.7 x 6.9"
|
