Description
The 9541 is a 15-conductor Computer Cable with 24AWG stranded (7 x 32) tinned copper conductors, semi-rigid PVC insulation, overall Beldfoil� aluminium foil-polyester tape shield (100% coverage) and chrome PVC jacket. Belden multi-conductor cable deliver low voltage analog data and signal transmission within enclosures from controllers and I/O's to devices such as temperature and pressure sensors, relays, valves, meters, thermocouples, solenoids, actuators, contactors, push buttons and alarms. This computer cable is designed for EIA RS-232 applications.
- 30pF/ft Conductor to conductor nominal capacitance
- 55pF/ft Conductor to other conductor and shield nominal capacitance
- 25R/1000ft at 20�C Nominal conductor DC resistance
- 18R/1000ft at 20�C Nominal outer shield DC resistance
- UL1685 FT4 Loading flame tested
Applications
Computers & Computer Peripherals
Product details
| No. of Cores | 15Core |
| Reel Length (Metric) | - |
| Conductor Material | Copper |
| Jacket Material | PVC |
| External Diameter | 7.21mm |
| Voltage Rating | 300V |
| Reel Length (Imperial) | - |
| Product Range | - |
| Wire Gauge | 24AWG |
| Jacket Colour | Chrome |
| No. of Max Strands x Strand Size | 7 x 0.2mm |
| Conductor Area CSA | 0.2mm� |
Other details
| Brand | BELDEN |
| Part Number | 9541 |
| Quantity | 1 Metre |
| Technical Data Sheet EN |  |
