Description
The 9540 from Belden is a multi conductor computer cable for EIA RS232 application. This cable is UL recognized and CSA certified.
- CPR: Not Yet Qualified
- Ten 24AWG stranded (7x32) tinned copper conductors
- Semi rigid polyvinyl chloride (PVC) insulation
- Overall Beldfoil shielding (100% coverage)
- Polyvinyl chloride (PVC) outer jacket
- Operating temperature range from -30°C to 80°C
- Overall nominal diameter is 6.198mm
- Nominal conductor to conductor capacitance of 98.43pF/m
- Nominal conductor DC resistance (DCR) of 82.025ohm/Km at 20°C
- Maximum operating voltage of 300Vrms (according to UL)
- Maximum recommended current of 1.75A per conductor at 25°C
Industrial, Communications & Networking
Other details
| Brand | BELDEN |
| Part Number | 9540 |
| Quantity | 1 Metre |
| Technical Data Sheet EN |  |
