Description
The 9538 from Belden is a multi conductor computer cable for EIA RS232 application. This cable is UL recognized and CSA certified.
- CPR: Not Yet Qualified
- Eight 24AWG stranded (7x32) tinned copper conductors
- Semi rigid polyvinyl chloride (PVC) insulation
- Overall Beldfoil shielding (100% coverage)
- Polyvinyl chloride (PVC) outer jacket
- Operating temperature range from -30°C to 80°C
- Overall nominal diameter is 0.224inch
- Nominal conductor to conductor capacitance of 33pF/ft
- Nominal conductor DC resistance (DCR) of 25ohm/1000ft at 20°C
- Maximum operating voltage of 300Vrms (according to UL)
- Maximum recommended current of 1.75A per conductor at 25°C
Applications
Industrial, Communications & Networking
Product details
| Cable Shielding: Screened |
| No. of Cores: 8Core |
| Wire Gauge: 24AWG |
| Conductor Area CSA: 0.2mm² |
| Reel Length (Imperial): - |
| Reel Length (Metric): - |
| Jacket Colour: Chrome |
| No. of Max Strands x Strand Size: 7 x 0.2mm |
| Conductor Material: Copper |
| Jacket Material: PVC |
| External Diameter: 5.59mm |
| Voltage Rating: 300V |
| Product Range: - |
Other details
| Brand | BELDEN |
| Part Number | 9538 |
| Quantity | 1 Metre |
| Technical Data Sheet EN |  |
