Description
The 8778 is a 6-pair CM-rated Multi-conductor Cable with 22AWG stranded (7x30) tinned copper conductor, polypropylene insulation, twisted pairs individually shielded with Beldfoil® aluminium foil-polyester tape (100% coverage) and overall chrome PVC jacket. Belden multi-conductor cable deliver low voltage analog data and signal transmission within enclosures from controllers and I/O's to devices such as temperature and pressure sensors, relays, valves, meters, thermocouples, solenoids, actuators, contactors, push buttons and alarms.
- CPR: Not Yet Qualified
- 50R Nominal characteristic impedance
- 0.18µH/ft Nominal inductance
- 30pF/ft Conductor to shield nominal capacitance
- 55pF/ft Conductor to other conductor and shield nominal capacitance
- 66% Nominal velocity of propagation
- 15R/1000ft at 20°C Nominal conductor DC resistance
- UL1685 Flame tested
Industrial
Other details
| Brand | BELDEN |
| Part Number | 8778 |
| Quantity | 1 Metre |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 2663.79 |
| 3-5 | ₹ 2636.61 |
| 5-10 | ₹ 2582.24 |
| 10+ | ₹ 2527.88 |
Bulk discount will be automatically applied during checkout based on quantity.
