| ₹ 124280.0 includes GST and import duties. | |
| B2B customers can avail ₹ 18952.7 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
Belden 5100UP Overview
The Belden 14-Gauge Twisted-Pair High-Strand Speaker Cable, 1000' long and in white, is used for connecting speakers and amplifiers in security, commercial, or residential AV systems. It features a twisted pair of unshielded, high-conductivity bare-copper conductors protected from the rigors of installation by a flexible and rugged black PVC jacket with ripcord.
This UL-certified cable offers a temperature rating of 167°F, and a maximum operating voltage of 300V. It comes on a reel for easy deployment.
In the Box
- Belden 14-Gauge Twisted-Pair High-Strand Speaker Cable (1000', White)
Belden 5100UP Specs
| Connector 1 |
No
|
| Connector 2 |
No
|
| Cable Length |
1000' / 304.8 m
|
| Conductor Material |
Bare Annealed Copper (BAC)
|
| Number of Conductors |
2
|
| Wire Gauge |
14 AWG
|
| Wire Stranding |
42x Strands of 30 AWG
|
| Outer Diameter |
0.27" / 6.75 mm
|
| Jacket Type |
Polyvinyl Chloride (PVC)
|
| Color |
Gray
|
| Shielding |
No
|
| Insulation Type |
Polyvinyl Chloride (PVC)
|
| Conductor Capacitance |
29 pF/ft
|
| Conductor DC Resistance |
0.0024 Ohms/ft (Up to 1000' / 304.8 m)
|
| Inductance |
0.17 ?H/ft
|
| Lay Length |
3.5" / 8.89 cm
|
| Maximum Current |
22 A
|
| Maximum Voltage |
300 V RMS (UL)
|
| Pulling Tension |
109.2 lb / 49.53 kg (Maximum)
|
| Bend Radius |
2.6" / 66.6 mm
|
| Rip Cord |
Yes
|
| Operating Temperature |
-4 to 167°F / -20 to 75°C
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 121794.4 |
| 3-5 | ₹ 120551.6 |
| 5-10 | ₹ 118066.0 |
| 10+ | ₹ 115580.4 |
Bulk discount will be automatically applied during checkout based on quantity.
