Description
Barco MatrixPRO-II Overview
The Barco MatrixPRO-II 8x8 Switcher with 3G SDI combines a high 600MHz bandwidth with a flat +/-1.0dB to 300MHz frequency to deliver image switching and signal distribution without any artifacts.
A genlock input synchronizes all switching with the house sync. A user-selectable RGB delay mode locks down-stream equipment to a new signal before anything is visible on the screen. And presets are available to be stored and allow easy system reconfiguration. I/O grouping and split-mode switching features divide the matrix into smaller sub-switchers and let each color channel switch independently.
Control can be by front panel buttons, by RS232, or via Ethernet connections. The switcher also fully integrates with Barco's Encore and ScreenPRO-II presentation systems and can be controlled through them.
8x8 Wideband Matrix Switcher
- Delivers switching and distribution without any artifacts
- A genlock input synchronizes all switching with the house sync
- Selectable RGB delay locks down-stream equipment to a new signal
- Presets are available to be stored and facilitate easy system reconfiguration
- I/O grouping and split-mode create sub-switchers and let each color channel switch independently
In the Box
- Barco MatrixPRO-II 8x8 Switcher with 3G SDI
- 3-Year Parts and Labor Warranty
Barco MatrixPRO-II Specs
| Supported Formats | DVB-ASI, SMPTE 259M, SMPTE 292M, SMPTE 424M; 270M bps - 2.97Gbps; 2K, 2048x1556/23.98 and 24 |
| Inputs | |
| Standard | SMPTE 259M / SMPTE 292M / SMPTE 424M |
| Data Rate | 270Mbps - 1.485Gbps / 2.97Gbps |
| Connector | 75 ohm BNC female |
| Impedance | 75 ohm nominal |
| Return Loss | > 15dB (5MHz - 1.485GHz); > 10dB (1.5 - 3GHz) |
| Cable Equalization | Automatic up to 230' (70m) @ 2.97Gbps, typical Belden 1694A Automatic up to 328' (100m) @ 1.485Gbps, typical Belden 1694A Automatic up to 984' (300m) @ 270Mbps, typical Belden 8281 |
| Outputs | |
| Connector | 75 ohm BNC female |
| Impedance | 75 ohm nominal |
| Return Loss | > 15dB (5MHz - 1.485GHz); > 10dB (1.5 - 3GHz) |
| Signal Level | 800mVp-p ±10% |
| Rise & Fall | - 20 - 80% - SD limit: 0.4 - 1.5ns, < 0.5ns rise/fall variation - HD limit: < 270ps, < 100ps rise/fall variation - 3G-HD limit: < 135ps, < 50ps rise/fall variation |
| Amplitude Overshoot | < 10% |
| Signal Polarity | Non-inverting electrical with respect to inputs |
| Power & Other Parameters | |
| Power | 14W |
| Signal Speed | Timing jitter: SD: < 0.2 UI; 3G-HD/HD: < 1UI Alignment jitter: SD: < 0.2UI; 3G-HD/HD: < 0.2UI |
| Safety Regulations | Compliant with CE EN55103-1 and 2 |
| Control | Serial port: RS-232, DB9 connector female Ethernet port: 10/100BaseT Ethernet bus, 1x RJ45 connector |
| Rack Mount | 1RU |
| Dimensions | 1.7 x 19 x 2" (4.4 x 48.3 x 5 cm) |
| Weight | 2.9 lbs (1.3 kg) |
