Description
BAE Audio B15 Overview
The B15 from BAE is a 500-series, hand-wired three-band equalizer with a Jensen transformer. It features a balanced input & output and has push-button shelving options for low and high frequencies. This module can be used by engineers, producers, and musicians in audio applications for recordings, broadcast TV, live sound reinforcement, and more.
The B15 features an all-discrete design, is built with Elma gold-plated rotary switches, and utilizes Avedis 1122 op amps. Furthermore, 16 dB of boost and cut can be achieved using the continuously variable potentiometer, providing high headroom with low noise output.
- BAE Audio B15 3-Band EQ 500-Series Module
- Limited 5-Year warranty
No additional resources available
BAE Audio B15 Specs
| Equalizer |
3-band (5x selectable each band)
|
| Frequencies |
Hi Frequency: 6, 8, 10, 12, & 16 kHz
Mid Frequency: 560 & 750 Hz, 1.5, 3, & 5 kHz Low Frequency: 63, 120, 200, 300, & 430 Hz |
| Boost and Cut |
+16 dB using continuous variable potentiometer
|
| Switches |
Elma gold-plated rotary switches
|
| Connector |
15-way
|
| Amp Types |
Avedis 1122 op amps
|
| Dimensions |
1.5 x 5.25" (3.8 x 13 cm)
|
| Weight |
Not specified by manufacturer
|
