- For TV, Film, and Video Production
- Mounts on Cinema and Mirrorless Cameras
- Supercardioid Polar Pattern
- 48V Phantom-Powered
- XLR Output with Hardwired 13" Cable
- Rugged Metal Construction, Rejects RF
- Includes Shockmount Holder
- Includes Foam Windshield
- Handcrafted in Japan
The Azden SGM-250CX is a short-length, compact shotgun microphone that easily mounts on cinema and mirrorless cameras, for film, documentary, interview or broadcast applications. Specifically tuned to preserve the natural qualities of a speaking subject, it features a supercardioid polar pattern and a custom-designed acoustic tube with high-precision phase-canceling slots that minimize the recording of extraneous noise while focusing on the sound in front of the camera.
The SGM-250CX is equipped with an electret condenser capsule that is powered by standard 48V phantom power. The highly sensitive capsule delivers a flat frequency-response (20 Hz to 20 kHz) with low self-noise and 130 dB SPL, for accurate audio capture.
Handcrafted in Japan, the SGM-250CX is housed in a brass/aluminum alloy case that improves durability and rejects ambient radio frequencies (RF). The mic comes with a 13"-long, hardwired XLR mic cable for convenient connection to a camera's microphone input. Included are a foam windscreen, and an SMH-X shockmount with two diameter expander sheets that provide a secure hold for your mic, whether you run-and-gun, mount it to a pistol grip or to a boompole.
-
- Short length and compact design ideal for mounting on cinema and mirrorless cameras
- Specifically tuned to preserve the natural qualities of a speaking subject
- Supercardioid polar pattern with narrow pickup area, provides enhanced directionality for isolating dialog from ambient noise
- Electret condenser microphone element delivers high sensitivity and low self-noise, for clear recording of quiet sounds
- Custom-designed acoustic tube with high-precision phase-canceling slots
- Powered by standard 48 VDC phantom power
- Flat frequency-response for accurate audio capture � 20 Hz to 20 kHz
- Wide dynamic range allows for capturing sounds at up to 112 dB, without distortion
- Brass/aluminum alloy case for improved durability and rejection of ambient RF
- Gold-plated, 3-pin XLR output connector with 13" hardwired cable extension � connects to camera microphone inputs
- Includes SMH-X shockmount � compatible with standard-size camera shoe slots, as well as 1/4-20-threaded boompoles and tripods
- Includes two diameter expander sheets with adhesive backing � wrap around the base of the microphone to allow for a secure fit in ring-clamps with diameter larger than 0.82"
- Includes foam windscreen and carry pouch
- Handcrafted in Japan
UPC: 095528701010
In the Box
Azden SGM-250CX Compact Shotgun Microphone
Azden SGM-250CX specs
| Analog Performance |
| Sound Field | Mono |
| Operating Principle | Not specified by manufacturer |
| Transducer | Electret Condenser |
| Diaphragm | Not specified by manufacturer |
| Polar Pattern | Supercardioid |
| Frequency Range | 20 Hz to 20 kHz |
| Signal to Noise Ratio | AB: 76 dB |
| Equivalent Noise Level | Not specified by manufacturer |
| Maximum SPL | 130 dB SPL |
| Pad | None |
| THD | Not specified by manufacturer |
| Impedance | 100 Ohms |
| Load Impedance | Not specified by manufacturer |
| Sensitivity | -33 dB at 1 kHz |
| Low-Cut Filter | None |
| Dynamic Range | 112 dB |
| General |
| Output Connectors | 1 x 3-Pin XLR |
| Cable Length | 12.99" / 330 mm |
| Operating Current Consumption | Not specified by manufacturer |
| Operating Voltage | 11 to 50 V |
| Operating Temperature | Not specified by manufacturer |
| Operating Humidity | Not specified by manufacturer |
| Storage Temperature | Not specified by manufacturer |
| Length | 6.02" / 153 mm |
| Diameter | 0.83" / 21 mm |
| Weight | 3.00 oz / 85 g |
| Packaging Info |
| Package Weight | 0.8 lb |
| Box Dimensions (LxWxH) | 10.3 x 3.6 x 2.7" |
