Description
AVPro Edge MXNet Overview
The MXNet 1G Downmixing Encoder/Transmitter Device from AVPro Edge is similar to the Encoder/Transmitter, but it also adds audio downmixing from Dolby Atmos, DTS-HD, and other high-end audio to embedded stereo via the HDMI output to accommodate stereo systems that don't have surround capabilities. The device connects to your network to send IP video for video walls, digital signage, or high resolution monitoring. The encoder inputs up to 4K60 4:4:4 video from the MXNet switch or a multicast-capable L3 switch over Gigabit Ethernet or extend the distance via an optional fiber module in the SFP slot, and it outputs HDMI video up to 4K60 to a local display for monitoring. The transmitter encodes HDMI video and transmits it with near zero latency with a maximum 1 GB/s data rate, outputting visually lossless video.
The transmitter/encoder fits right into the MXNet device ecosystem, and it can be configured and managed by the MXNet MENTOR control tool. Other features include EDID support, HDR and Dolby Vision support, DTS and Dolby audio support, a data status display, RS-232 and IR signaling pass-through support, USB and KVM support, and you can even turn off all the LED status lights on the unit so it can be installed discreetly.
Key Features
Downmixing
JPEG 2000
Data Window
Full External Light Control
Control Signal Routing
USB and KVM Support
In the Box
- AVPro Edge MXNet 1G Downmixing Encoder/Transmitter Device
- IR Emitter
- IR Eye
- 2 x Rack Ear
- 4 x Screw
- 2 x 3-Pin Terminal Block Connectors
- Limited 10-Year Warranty
AVPro Edge MXNet Specs
| Video Input Connectors | 1 x HDMI (DVI / HDMI 2.0b) Female |
| Input Video Format | HDMI (4:4:4/4:2:2) DCI 4K: 30/60 fps RJ45 (4:2:0) DCI 4K: 60 fps RJ45 (10/12-Bit 4:4:4/4:2:2/4:2:0) 1080p |
| Audio Input Connectors | 1 x 1/8" / 3.5 mm TRS Stereo Analog Female |
| Embedded Audio Input | RJ45 HDMI |
| Video Output Connectors | 1 x RJ45 Female |
| Output Video Format | HDMI / RJ45 (10/12-Bit 4:4:4/4:2:2) DCI 4K: 30/60 fps HDMI / RJ45 (10/12-Bit 4:2:0) DCI 4K: 60 fps HDMI / RJ45 (16-Bit 4:4:4/4:2:2/4:2:0) 1080p |
| Audio Output Connectors | 1 x 5-Pin Euroblock Stereo Analog Female |
| Output Audio Format | Analog LPCM (Linear Pulse-Code Modulation) |
| Embedded Audio Output | HDMI RJ45 |
| EDID Support | Manual Control |
| HDR Compatibility | HDR10, Dolby Vision, Hybrid Log Gamma |
| DTS Compatibility | DTS, DTS-ES, DTS-HD High Resolution |
| Dolby Compatibility | Dolby Digital, Dolby Digital Plus |
| Other I/O | 3 x 3.5 mm IR Input/Output 1 x 5-Pin Euroblock RS-232 Input/Output 1 x USB Type-B Input 1 x USB Micro-B Firmware Input |
| Expansion Slots | 1 x SFP Slot |
| Wi-Fi Support | Yes |
| Power Connector | 1 x Barrel (12 VDC at 2 A) Input |
| PoE Support | PoE 802.3af |
| Power Consumption | Power Supply: 120 to 240 VAC at 0.8 A (6.5 W) |
| Operating Temperature | 23 to 123°F / -5 to 51°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 5 to 90% |
| Certifications | CE, FCC, UL, as per Manufacturer |
| Dimensions | 7.9 x 4.1 x 0.8" / 200 x 104 x 20 mm |
| Weight | 1.2 lb / 550 g |
