Description
AVMATRIX VC41 Overview
- 1Description
- 2High Bandwidth and Ultralow Latency
- 324-Hours of Non-Stop Work
- 4Portrait and Landscape Modes
- 5Compatibility
Simultaneously livestream and capture your gameplay or content creation using this VC41 1080p 3G-SDI PCIe 4-Channel Capture Card from AVMATRIX with its four 3G-SDI inputs. The PCIe 2.0x4 interface supports up to 1080p60 YUY2 uncompressed video for a high-quality picture.
The image integrity is further preserved thanks to the 1080i hardware deinterlacing and 3D noise reduction algorithm. Compatible with Windows and Linux operating systems, the card is capable of recording to applications like OBS and Teams and livestreaming the captured video to major platforms.
High Bandwidth and Ultralow Latency
The PCIe 2.0 interface has 2.5GB/s transmission bandwidth for faster data transfer speed in gaming and livestream applications, bringing uncompressed and ultralow latency to the streaming experience.
24-Hours of Non-Stop Work
The card has a thick gold-plated interface for more stable contact and transmission to work continuously for a long period of time.
Portrait and Landscape Modes
Supports portrait and landscape modes for various social media livestream scenarios.
Compatibility
Windows 7 and Linux 18.04 operating systems and above are supported by the card. Streaming and recording via OBS, Teams, Twitch, and other platforms is also supported for broadcast to major livestreaming platforms like YouTube and Facebook via the network.
Table of Contents
- Description
- High Bandwidth and Ultralow Latency
- 24-Hours of Non-Stop Work
- Portrait and Landscape Modes
- Compatibility
AVMATRIX VC41 Specs
| System Connection | PCIe 2.0 x4 |
| Video Inputs | 4 x BNC (3G-SDI / HD-SDI / SD-SDI) Female |
| Audio Inputs | None |
| Simultaneous Multi-Input Support | Yes: 4 Simultaneous Inputs |
| Input Video Format | SDI 1080p 60 fps |
| Input Audio Format | LPCM (Linear Pulse-Code Modulation): 48 kHz / 16-Bit |
| Output Video Format | SDI 1080p 25/30/50/59.94/60 fps UXGA (1600 x 1200) 60 fps HD+ (1600 x 900) 60 fps WXGA+ (1440 x 900) 60 fps SXGA (1280 x 1024) 60 fps WXGA (1280 x 800) 60 fps 1280 x 720 (Non-Standard WXGA) 25/30/50/59.94/60 fps XGA (1024 x 768) 60 fps SVGA (800 x 600) 30/60 fps 576p 30/60 fps 480p 30/60 fps |
| Output Audio Format | LPCM (Linear Pulse-Code Modulation): 48 kHz / 16-Bit |
| Embedded Audio | SDI |
Standards
| HDR Compatibility | Not Specified by Manufacturer |
Hardware
| OS Compatibility | Windows 7 or Later Linux 18.4 or Later *As of August, 2022: Check with manufacturer for the most up-to-date compatibility |
| Power Consumption | Device: 2 W |
Environmental
| Operating Temperature | 32 to 140°F / 0 to 60°C |
| Storage Temperature | -4 to 158°F / -20 to 70°C |
| Operating Humidity | 5 to 90% (Non-Condensing) |
General
| Dimensions | 4.7 x 3.5 x 0.9" / 120.1 x 88.4 x 21.6 mm |
| Weight | 5.3 oz / 150 g |
Packaging Info
| Package Weight | 0.505 lb |
| Box Dimensions (LxWxH) | 5.9 x 4.6 x 1.4" |
