Description
AVer PTR323NV2 Overview
- 1Description
- 2PTZ Livestreaming
- 3AI Powered Auto-Tracking Modes
- 4Other Interface Features
PTZ Livestreaming
Equipped with NDI|HX2 support, improved AI auto-tracking, and powerful livestreaming capabilities, the
TR323NV2 Auto-Tracking Livestreaming UHD 4K NDI PTZ Camera with 21x Optical Zoom from
AVer is made to maximize your presentations in your conference or educational space. The camera itself features a 1/2.8" CMOS sensor capable of capturing up to UHD 4K video and outputting it over its 3G-SDI, HDMI, USB-B, or IP connections. 21x optical zoom and 12x digital zoom and a 52.26° horizontal field of view maximize your visibility.
AI Powered Auto-Tracking Modes
Presenter Tracking
- Program the TR323NV2 to track your speaker as they move about the room for improved visibility for remote meeting participants.
- With manual programming, using the included remote control or via Web UI desktop software, you can track the speaker's full body, half body, or even add an additional speaker.
Zone Tracking
- For a professional webinar or keynote presentation, Zone Tracking can establish preset zones in a space and enhance the capture of content on multiple displays.
- Excels in applications where your presenter has rehearsed movement across a stage or wants to display pre-made visuals.
Hybrid Mode
- Find a happy medium with Hybrid Mode and switch between Presenter and Zone presets.
- Combine the best features of both and track the presenter freely or display fixed content like graphs and data.
Other Interface Features
Voice Tracking
Using PTZ Link and compatible microphones, your PTZ camera can follow the boardroom conversation for a more seamless integration of both remote and in-person participants. Accomplish this by setting preset points and integrating your microphone into the 3.5mm audio input on the camera.
Video Performance and Control
The camera offers a Wide Dynamic Range using special algorithms to balance dark or bright lighting for one clear image. 3G-SDI, HDMI, USB-B, and IP outputs increase connectivity across a wide variety of sources, including popular video/streaming platforms like Zoom and Microsoft Teams. RS-232 and RS-422 ports offer VISCA and Pelco-D protocols while the IP connection offers CGI control. Free desktop and iPadOS app downloads for users and AV managers control the camera via a Web UI interface.
Physical Features
- An integrated tally light turns red when camera is active, great for multi-camera applications for live video
- Includes ceiling mount bracket and cable fixing plate for permanent installation
- IR receiver at the front of the camera and remote offer another control option
In the Box
- AVer TR323NV2 Auto-Tracking Livestreaming UHD 4K NDI HX PTZ Camera with 21x Optical Zoom
- AVer Camera Ceiling Mount for PTZ Series TR311HN/TR311/TR313/TR333
- AVer 8-Pin DIN to 9-Pin D-Sub RS-232 Connector Cable for PTZ310 and PTZ330
- AVer RS-232 In/Out Y-Cable for PTZ310 and PTZ330 Cameras
- Cable Fixing Plate
- 3 x M2 Screw
- 3 x M3 Screw
- 2 x 6.5mm Screw
- Remote Control
- Drilling Paper
- 4 x Cable Tie
- Power Adapter and Cord
Table of Contents
- Description
- PTZ Livestreaming
- AI Powered Auto-Tracking Modes
- Other Interface Features
AVer PTR323NV2 Specs
Imaging
| Sensor Type | 1/2.8"-Type CMOS Sensor |
| Horizontal Resolution (TV Lines) | 1400 TV Lines |
| Sensor Resolution | Effective: 8 Megapixel |
| IR Cut Filter | No |
| Built-In ND Filter | None |
| Focus Control | Autofocus Manual Focus |
Exposure Control
| Shutter Speed | 1/10000 to 1/1 Second |
| Precise Scan Rate Control | No |
| Signal-to-Noise Ratio | 50 dB |
| Minimum Illumination | 0.5 Lux at 1/30 Shutter Speed |
| Flip / Mirror Support | Image Flip, Mirror (Vertical) |
Lens
| Focal Length | 5.3 to 110mm |
| Optical Zoom Ratio | 21x |
| Max Digital Zoom | 12x |
| Field of View | Horizontal: 2.66 to 52.26° Vertical: 2 to 41.26° Diagonal: 3.3 to 66.4° |
| Maximum Aperture | f/1.6 to 3.8 |
| Minimum Focus Distance | Wide: 4.9' / 1.5 m Telephoto: 4.9' / 1.5 m |
Video Capture
| External Recording Modes | SDI/BNC / HDMI / RJ45 / USB UHD 4K (3840 x 2160) at 25/29.97/30.00 fps 1920 x 1080p at 25/29.97/30.00/50/59.94/60.00 fps 1280 x 720 at 25/29.97/30.00/50/59.94/60.00 fps |
| Embedded Audio | HDMI/LAN (RJ45)/SDI/USB-B: 2-Channel |
| Internal Recording Modes | M-JPEG UHD 4K (3840 x 2160) |
| Audio Recording | 2-Channel 48 kHz AAC LC Audio 48 kHz LPCM Audio |
| Broadcast Output | NTSC/PAL |
| IP Streaming | H.264, H.265, MJPEG, NDI|HX, RTMP, RTP, RTSP 3480 x 2160 at 30p (0.52 to 32.00 Mb/s) |
| IP Multi-Stream Support | Selectable Combination H.264, H.265, MJPEG, RTMP, RTP, RTSP, TCP, UDP: UHD 4K, 1080p at 30p H.264, H.265, MJPEG, RTMP, RTP, RTSP, TCP, UDP: 720p H.264, H.265, MJPEG, RTMP, RTP, RTSP, TCP, UDP: 1080p at 60p |
Control
| Presets | 10 via IR 256 via RS-232 |
| Move Speed | Pan: 200°/sec Tilt: 200°/sec |
| Movement Range | Pan: 340° (-170 to 170°) Tilt: 120° (-30 to 90°) |
| Tally Light | Yes |
| Supported Control Protocols | CGI IP IR NDI Pelco-D RS-232 RS-422 VISCA |
Interface
| Video I/O | 1 x HDMI Output 1 x BNC (3G-SDI) Output 1 x USB-B 3.0 / 3.1/3.2 Gen 1 Output 1 x RJ45 (NDI) Input/Output |
| Audio I/O | 1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input |
| Other I/O | 1 x DIN 8-Pin (RS-232) Control Input 1 x RJ45 (RS-422) Input |
| Built-In Speaker | No |
Power
| PoE Support | PoE+ 802.3at |
| Power I/O | 1 x Barrel (12 VDC) Input |
| Power Consumption | Device: 19 W |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 20 to 80% |
| Storage Humidity | 20 to 95% |
General
| App Compatible | Yes: iPadOS Only App Name: AVer PTZ Control Panel Functionality: Remote Control *As of November, 2022: Check with manufacturer for the most up-to-date compatibility |
| Security Lock Support | Kensington Lock Slot |
| Dimensions (W x H x D) | 7.1 x 7.6 x 5.7" / 180 x 192 x 145 mm |
| Weight | 4.4 lb / 2 kg |
Packaging Info
| Package Weight | 9.015 lb |
| Box Dimensions (LxWxH) | 12.7 x 10.8 x 10.2" |
