Description
Avenview C6MWIP Overview
Expand your matrix and video wall setup by adding this H.264/1080p Receiver/Decoder from Avenview to your Encoder/Decoder video matrix set. The decoder features a Cat 5e/6 LAN input and HDMI 1.3 output and can be run point-to-point direct from an encoder or point-to-multi from a network switch up to 330' away.
The receiver/decoder unit supports up to 1080p60 on input and output, auto scaling and rotation, automatic format detection, live preview, HDCP 1.4, and the full system uses H.264/MPEG-4 AVC video compression. It can be powered using the included 12 VDC international power adapter or by using your existing PoE (Power-over-Ethernet) network. You can also de-embed analog audio from the encoder using the stereo terminal block output. To configure the unit you can utilize telnet, a web GUI, or you can utilize serial controllers via an API using the RS-232 terminal block.
Key Features
In the Box
- Avenview H.264/1080p Receiver/Decoder for Video Wall/Matrix
- 12 VDC International Power Supply Kit
- Mounting Bracket Set
- 2 x Phoenix Connector (3-Pin Male)
- Limited 3-Year Warranty
Avenview C6MWIP Specs
| Video Input Connectors | 1 x RJ45 (HDMI 1.3) Female |
| Input Video Format |
RJ45 1080p: 60 fps |
| Audio Input Connectors | None |
| Embedded Audio Input | RJ45: 2-Channel |
| Video Output Connectors | 1 x HDMI (HDMI 1.3) Female |
| Output Video Format | HDMI 1080p: 24/25/30/50/60 fps 720p: 50/60 fps 720 x 540: 60 fps WUXGA+ (1680 x 1050): 60 fps SXGA+ (1400 x 1050): 60 fps WXGA+ (1440 x 900): 60 fps FWXGA (1366 x 768): 60 fps SXGA (1280 x 1024): 60 fps WXGA (1280 x 800): 60 fps XGA (1024 x 768): 60 fps 576p: 50 fps 480p: 60 fps NTSC: 60 fps |
| Audio Output Connectors | 1 x 3-Pin Euroblock Stereo Analog Female |
| Embedded Audio Output | HDMI: 2-Channel |
| HDCP Support | Version 1.4 |
| Latency | HDMI Output: 50 to 250 ms |
| Other I/O | 1 x 3-Pin Euroblock RS-232 Input/Output |
| Expansion Slots | None |
| Video IP Decoding | MP4, H.264: 720 x 480 to 1920 x 1080 at 60p |
| Power Connector | 1 x Barrel (12 VDC at 1 A) Input |
| PoE Support | PoE 802.3af |
| Power Consumption | Device: 12 VDC at 1 A (6 W) |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 20 to 90% |
| Dimensions | 6.9 x 3.9 x 0.98" / 17.5 x 9.9 x 2.49 cm |
| Weight | 1.32 lb / 599 g |
| Warranty Length | Limited 3-Year Warranty |
| Package Weight | 1.975 lb |
| Box Dimensions (LxWxH) | 9.1 x 6.8 x 2.2" |
