Autocue DN-VGA Overview
The Autocue VGA Video Splitter (1x4) by Kramer outputs a single VGA signal to 4 devices. This device is ideal when you need to send the same computer VGA signal out to multiple prompters.
Along with a high bandwidth of 400MHz and ID bit control this device incorporates Kramer's Kr-isp Advanced Sync Processing which, by restoring the sync signal waveform, overcomes the problem of low sync, thus ensuring compatibility with a greater range of computer devices.
EDID PassThru is another important function used by this device to pass EDID/HDCP signals from a source to the display. An optional rack adapter (RK-3T) is available for installing three of these units, side by side, in a 1U rack space.
Kr-isp Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr?isp advanced sync processing can be enabled or disabled.
EDID PassThru - Passes EDID/HDCP signals from source to display.
Selectable Sync Input Impedance - 75? (video), 510? (Graphics/TTL)
Compact Kramer TOOLS - 3 units can be rack mounted side?by?side in a 1U rack space with the optional RK?3T rack adapter
In the Box
- Autocue VGA Video Splitter (1x4)
- 3' (0.9 m) VGA Male/Male Cable
- Power Supply (5VDC/2.6A)
- Mounting Bracket
Autocue DN-VGA Specs
Interfaces
| Input |
1 x DE-15/DB-15 (VGA) |
| Output |
4 x DE-15/DB-15 (VGA) |
Transmission
| Bandwidth |
400 MHz at -3 dB |
| Differential Gain |
0.03% |
| Differential Phase |
0.03° |
| Signal-to-Noise Ratio |
72 dB at 5 MHz |
| Signal Level |
2.2 Vp-p (Output) |
Power
| Power Consumption |
5 VDC at 130 mA |
General
| Dimensions |
4.8 x 2.8 x 1.0" / 122.0 x 71.0 x 25.0 mm |
| Weight |
0.7 lb / 0.3 kg |
