Description
Asustor AS6704T Overview
- 1Description
- 2Powered by an Intel Celeron Quad-Core Processor
- 3Four M.2 Slots
- 4Keeping Cool
- 5Tool Free M.2 SSD Installation
- 62.5 + 2.5 = Extreme Speeds
- 7SMB Multichannel (RAID 5)
- 8PCIe 3.0 - Doubled SSD Performance
- 9USB 3.2 Gen 2 Type-A Ports
- 10Removing your Storage Constraints
- 11Adobe and ASUSTOR - A Winning Combination
- 12Creativity Knows No Bounds
- 13The Ultimate Live Streaming Tool
- 14Comprehensive Backup and Virtualization Solution
- 15More Efficient
- 1624/7 Reliability and Durability
- 17Protected From the Inside and Out
- 18Protected from Ransomware
- 19Exclusive MyArchive Cold Backup Technology Unlimited Capacity Expansion
- 20Snapshot Center
- 21DataSync Center
- 22Cloud Backup Center
- 23ASUSTOR EZ Sync
Designed to handle intensive tasks such as direct video editing, the Lockerstor 4 Gen2 4-Bay NAS Enclosure from Asustor offers the speed and capabilities to take on almost any project. In addition to featuring four 3.5"/2.5" SATA drive bays, this high-performance network storage enclosure has four M.2 2280 NVMe PCIe 3.0 SSD slots that may be configured for cache or storage. You can also mix and match M.2 configurations and set up RAID modes depending on your needs. The dual 2.5G Ethernet ports support SMB multichannel technology, which allows you to combine their throughput to reach 5G speeds with compatible devices, giving you the bandwidth to share massive files with your team. Powered by a 2.0 GHz Intel Celeron N5105 quad-core processor with 4GB of DDR4-2933 memory, the Lockerstor 4 Gen2 can deliver up to 590 MB/s read and 555 MB/s write speeds in RAID 5 configuration.
Install a 10G Ethernet network adapter into the PCIe slot for even greater performance. Please note that the PCIe slot is occupied by an M.2 daughter board with all four of the system's M.2 SSD slots. Installing an expansion card requires its removal. The two memory slots support up to 16GB total. Other features include two USB 3.2 Gen 2 Type-A slots that can transfer data at up to 10 Gb/s with compatible devices.
Powered by an Intel Celeron Quad-Core Processor
The Lockerstor Gen2 comes with a 2.0 GHz Intel Celeron N5105 Quad-Core processor. The N5105 comes with Intel's 10nm technology and is up to 31% faster than Gemini Lake SoCs. The Celeron N5105 is clocked at 2.0 GHz with a boost speed of up to 2.9 GHz, enabling efficient content creation with the added flexibility of 10 Gigabit Ethernet upgrades.
Four M.2 Slots
The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching, storage, or both. Either use all slots for one purpose or mix and match depending on your needs. Four M.2 SSD slots bring a number of custom scenarios to your NAS when it comes to accelerating your storage.
Keeping Cool
With up to four SSDs, a considerable amount of heat can be generated. With extra ventilation, the Lockerstor Gen2 ensures that all components in your NAS receive cooling.
Tool Free M.2 SSD Installation
Use latches instead of screws for easier installation.
2.5 + 2.5 = Extreme Speeds
The Lockerstor Gen2 has two 2.5GbE ports, which more than doubles the performance of Gigabit Ethernet devices. But, that's not all. With the recent introduction of support for SMB Multichannel, your NAS will be able to combine the speed of multiple Ethernet ports for speeds way beyond 2.5 Gigabit Ethernet.
SMB Multichannel (RAID 5)
Achieve read speeds of up to 590 MB/s and write speeds of up to 555 MB/s.
PCIe 3.0 - Doubled SSD Performance
PCIe 3.0 is supported by the Lockerstor Gen2 series of NAS devices, which almost doubles the performance of M.2 SSDs installed in your NAS, ensuring a smoother SSD experience.
USB 3.2 Gen 2 Type-A Ports
The Lockerstor Gen2 series supports USB 3.2 Gen 2, so you can enjoy up to double the performance compared with USB 3.2 Gen 1, at up to 10 Gb/s.
Removing your Storage Constraints
Edit videos directly on your NAS with Adobe Premiere or Final Cut Pro. Both applications, as well as the full suite of Adobe software, are supported on your ASUSTOR NAS, ensuring that the SSD on your laptop is no longer a constraint.
Adobe and ASUSTOR - A Winning Combination
Local Adobe Creative Cloud folders can be synchronized and backed up to and from your NAS. Take advantage of snapshots to increase protection of your data.
Creativity Knows No Bounds
Your ASUSTOR NAS can work as a hybrid cloud that enables data accessibility both locally and through public cloud providers, ensuring easy collaboration regardless of location.
The Ultimate Live Streaming Tool
Create your own streaming and backup center for YouTube and Twitch.
Comprehensive Backup and Virtualization Solution
More Efficient
Easily transcode 10-bit 4K H.265 media with hardware decoding and smooth video playback in LooksGood for the ultimate in 4K enjoyment.
24/7 Reliability and Durability
All ASUSTOR NAS are designed for and are suitable for 24/7 use. ASUSTOR NAS devices have also undergone rigorous tests, such as drop tests and burn tests, to test durability in extreme conditions. Heat sinks were added to sensitive components to dissipate heat, helping to maintain the longevity of the device.
Protected From the Inside and Out
Protect your data from loss, damage, and attacks with the ASUSTOR NAS. An ASUSTOR NAS is better protected by running the Linux-based ADM, employing a built-in firewall, ClamAV Antivirus, MyArchive, and ADM's various backup tools help protect ransomware even better.
Network Attack Protection
Firewall
ADM Defender
Cloud Backup Center offsite backups
Secure Data Transmission
VPN connection
SSL certificate connection
Automatic logout
Internal Data
MyArchive on and offsite backups
AES-256 folder encryption
Antivirus software
Access Control
File/folder/app isolation
2-Step Verification
Wake on LAN (WOL)
Wake on WAN (WOW)
Network Attack Protection
Secure Data Transmission
Internal Data
Access Control
Protected from Ransomware
The Lockerstor comes with the most up-to-date version of ADM to help protect against ransomware attacks, with Snapshot Center and Btrfs providing efficient snapshots to easily restore lost data. Other security features found on the Lockerstor are the ability to create one or more replacement administrator accounts, a firewall by ADM Defender that features black and white lists and the ability to change default ports, disable SSH, and Terminal to prevent remote attacks. MyArchive cold storage hard drive security can also be increased by implementing AES 256-bit encryption.
Exclusive MyArchive Cold Backup Technology Unlimited Capacity Expansion
MyArchive cold storage technology turns NAS hard drives into removable storage archive drives. Directly insert a MyArchive hard drive into a free bay inside your NAS to easily access, backup, and share terabytes of content.
Snapshot Center
Snapshot Center is a feature for ASUSTOR NAS devices to utilize Btrfs and iSCSI volumes to take snapshots of the information inside a NAS. Snapshot Center supports up to 256 snapshots of a volume and can be done every five minutes, creating a backup that can be restored easily if data is damaged or lost. MyArchive now supports Btrfs and snapshots. Btrfs for MyArchive supports snapshots and version history to help protect against accidental deletions or modifications.
DataSync Center
DataSync Center combines multiple cloud services into a single app. DataSync Center includes, but is not limited to Google Drive, Dropbox, OneDrive, and Yandex and supports multitasking as well as multiple accounts. Control your data with instant and scheduled backups as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.
Cloud Backup Center
Cloud Backup Center brings support for various business cloud services including, but not limited to Amazon S3, Backblaze B2, Baidu Cloud, IBM Cloud, Rackspace Cloud Files, Microsoft Azure Blob Storage, Alibaba Cloud, SFTP, and WebDAV. Control your data with instant and scheduled backups, as well as using Cloud Backup Center to create a hybrid cloud that keeps your data online and offline, keeping your data protected.
ASUSTOR EZ Sync
UPC: 887372901612
In the Box
- Asustor Lockerstor 4 Gen2 4-Bay NAS Enclosure
- 2 x RJ45 Cat 5e LAN Cables
- 16 x Flat Head Screws for 3.5" HDDs
- 16 x Flat Head Screws for 2.5" HDDs
- AC Power Cord
- AC Power Adapter
Table of Contents
- Description
- Powered by an Intel Celeron Quad-Core Processor
- Four M.2 Slots
- Keeping Cool
- Tool Free M.2 SSD Installation
- 2.5 + 2.5 = Extreme Speeds
- SMB Multichannel (RAID 5)
- PCIe 3.0 - Doubled SSD Performance
- USB 3.2 Gen 2 Type-A Ports
- Removing your Storage Constraints
- Adobe and ASUSTOR - A Winning Combination
- Creativity Knows No Bounds
- The Ultimate Live Streaming Tool
- Comprehensive Backup and Virtualization Solution
- More Efficient
- 24/7 Reliability and Durability
- Protected From the Inside and Out
- Protected from Ransomware
- Exclusive MyArchive Cold Backup Technology Unlimited Capacity Expansion
- Snapshot Center
- DataSync Center
- Cloud Backup Center
- ASUSTOR EZ Sync
Asustor AS6704T Specs
Computing
| CPU | 2 to 2.9 GHz Quad-Core |
| Processor | Intel Celeron N5105 (11th Gen) |
| GPU | Intel UHD Graphics |
| Total Installed Memory | 4 GB 2933 MHz DDR4 |
| User-Replaceable Memory | 1 x 4 GB |
| Total Memory Slots | 2 x SO-DIMM |
| Maximum Memory Capacity | 16 GB |
| Flash Memory | 8 GB eMMC |
General
| Number of Bays | 4 x 2.5"/3.5" 4 x M.2 (2280) |
| I/O | 2 x USB Type-A (USB 3.1 / USB 3.2 Gen 2 (10 Gb/s)) 1 x HDMI Type-A (HDMI 2.0b) 2 x RJ45 (2.5GbE) |
| Compatible Drive Interface | SATA (Unspecified Version) |
| Media Card Slots | None |
| Form Factor | Desktop |
| RAID | RAID 0, 1, 10, 5, 6, JBOD |
| Hot-Swap Support | Yes |
| PCI Expansion | 1 x PCIe 3.0 (Occupied) |
| Wake on LAN | Yes |
| Link Aggregation and Failover Support | Yes |
Networking
| Supported Protocols | AFP CIFS/SMB FTP HTTP HTTPS IPv4 IPv6 NFS Proxy Rsync SAN SFTP SMB 3.0 SNMP SSH Syslog TFTP WebDAV iSCSI |
| iSCSI LUN | 256 |
| iSCSI Target | 256 |
| Max Concurrent Connections | 512 |
| Max Folders | 512 |
| Max Groups | 512 |
| Max User Accounts | 4096 |
Software
| Supported File Systems | Internal: BTRFS, EXT4 External: BTRFS, EXT3, EXT4, FAT32, HFS+, NTFS, exFAT |
| OS Compatibility | Windows 11 Windows 10 Windows 8 Windows 7 Windows Vista Windows XP Windows Server 2022 Windows Server 2019 Windows Server 2016 Windows Server 2012 Windows Server 2008 macOS UNIX Linux FreeBSD *As of August, 2022: Check with manufacturer for the most up-to-date compatibility |
| Supported Browsers | Chrome, Edge, Firefox, Safari |
Security
| Encryption | 256-Bit AES |
Electrical
