Description
Asustor Lockerstor 12RD External HDD/SSD Overview
Quickly expand your small or medium business's network storage capacity for smooth backups, file sharing, and more with the Asustor LOCKERSTOR 12RD AS6512RD 12-Bay Rackmount NAS Enclosure. This 2 RU rackmount NAS supports up to twelve 3.5"/2.5" SATA III drives, which can be configured for RAID 0, 1, 5, 6, 10, Single or JBOD modes to balance between security and performance according to your needs. Integrate the NAS into your network using the dual Gigabit Ethernet ports and two 2.5G Ethernet connectors. The LOCKERSTOR 12RD AS6512RD is designed to deliver read speeds of up to 591 MB/s with 565 MB/s write speeds when both 2.5G Ethernet ports are combined through link aggregation for 5G Ethernet speeds and the drives are in RAID 5 configuration. Performance can be boosted to 1180 MB/s read and write speeds by installing a compatible 10G Ethernet adapter into the available PCIe 3.0 x8 slot.
Other convenient features include two redundant 350W power supplies and four USB 3.2 Gen 1 Type-A ports that can transfer up to 5 Gb/s of data with compatible devices such as storage expansion systems. The Asustor LOCKERSTOR 12RD AS6512RD 12-bay rackmount NAS enclosure has the ADM operating system installed, which supports a variety of backup, virtualization, and security applications.Reliable performance
Equipped with a 2.1 GHz Intel Atom C3538 quad-core processor with 8GB of DDR4-2133 memory, the LOCKERSTOR 12RD AS6512RD delivers smooth backup, archiving, and file sharing experiences. The memory can be expanded to 128GB for greater multitasking efficiency.
Cross-Platform Multi-User Access
The Asustor LOCKERSTOR 12RD AS6512RD NAS enclosure supports up to 4096 accounts with 512 concurrent connections from a multitude of platforms, including Windows PCs, Macs, Unix systems, and mobile devices. It also supports up to 512 groups and shared folders.
Storage Expansion
Add up to 216TB of storage to your network by installing twelve 18TB 3.5" hard drives.
Comprehensive Backup Solutions
Backup & Enterprise Virtualization Support
"Find Me" Function
Quickly locate your NAS enclosure for service and upgrades, even in darkened rooms by using a dedicated front panel button to activate a bright LED light. The light may also be activated remotely through the Asustor NAS management mobile app.
ADM Security
Network Attack Protection
Secure Data Transmission
Internal Data Protection
Access Control
UPC: 887372138407
In the Box
- Asustor LOCKERSTOR 12RD AS6512RD 12-Bay Rackmount NAS Enclosure
- 2 x Power Cables
- 2 x RJ45 Ethernet Cables (Cat 5e)
- 48 x Flat Head Screws for 3.5" Hard Drives
- 48 x Flat Head Screws for 2.5" Drives
- Limited 3-Year Warranty
Asustor Lockerstor 12RD External HDD/SSD Specs
Computing
| CPU | 2.1 GHz Quad-Core |
| Processor | Intel Atom C3538 |
| Total Installed Memory | 8 GB 2133 MHz DDR4 |
| User-Replaceable Memory | 1 x 8 GB |
| Total Memory Slots | 4 x SO-DIMM |
| Maximum Memory Capacity | 128 GB |
| Flash Memory | 8 GB eMMC |
General
| Number of Bays | 12 x 2.5"/3.5" |
| I/O | 2 x RJ45 (Gigabit Ethernet) 2 x RJ45 (2.5GbE) 4 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s)) |
| Compatible Drive Interface | SATA III |
| Media Card Slots | None |
| Maximum Filled Capacity | 216 TB 432 GB (with Expansion) |
| Form Factor | Rackmount (2 RU) |
| RAID Modes | RAID 0, 1, 10, 5, 6, JBOD, Single |
| Hot-Swap Support | Yes |
| PCI Expansion | 1 x PCIe 3.0 (x8 Electrical) |
| Wake on LAN | Yes |
| Link Aggregation and Failover Support | Yes |
Networking
| Supported Protocols | AFP CIFS/SMB FTP HTTP HTTPS IPv4 IPv6 NFS Proxy Rsync SAN SFTP SNMP SSH Syslog TFTP WebDAV iSCSI |
| iSCSI LUN | 512 |
| iSCSI Target | 256 |
| Max Concurrent Connections | 512 |
| Max Folders | 512 |
| Max Groups | 512 |
| Max User Accounts | 4096 |
| Max Cameras Supported | 64 |
Software
| Installed Operating System | ADM |
| Supported File Systems | Internal: BTRFS, EXT4 External: BTRFS, EXT3, EXT4, FAT32, HFS+, NTFS, exFAT |
| OS Compatibility | Windows XP or Later Windows Server 2003 or Later macOS UNIX Linux FreeBSD |
| Supported Browsers | Chrome, Edge, Firefox, Safari |
Security
| Encryption | 256-Bit AES (-Based) |
Electrical
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Source | AC Adapter |
| Power Consumption | 115 W (Typical) 67 W (Idle) |
| PSU Wattage | 3 x 350 W (Supports Redundancy) |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 5 to 95% |
Physical
| Status Monitoring | LED Indicator |
| Audible Alarm | No |
| Cooling | 2 x 60 mm Fans |
| Built-In Speakers | None |
| IR Sensor | None |
| Weight | 25.8 lb / 11.7 kg |
Packaging Info
| Package Weight | 37.69 lb |
| Box Dimensions (LxWxH) | 28.3 x 23.3 x 10.9" |
Asustor Lockerstor 12RD External HDD/SSD Reviews
