Description
ARX MIXXMAKER Overview
The ARX MIXXMaker is a versatile 1 RU multi-channel master mixer designed to meet the needs of today?s dynamic AV environments. Whether you?re mixing audio for corporate presentations, hospitality venues, fitness studios, or live sound reinforcement, the MIXXMaker offers flexible input options, professional-grade control, and rock-solid reliability?all in a user-friendly layout. From wireless Bluetooth streaming to USB playback and multiple analog inputs, the MIXXMaker handles the wide variety of audio sources used in modern installations with ease.
A Mixer for Every Source
The MIXXMaker includes dedicated inputs for:
- Bluetooth wireless audio (with front-panel level control)
- USB playback (with activity LED and level control)
- 3.5mm minijack input for phones, tablets, and laptops
- Two balanced mic/line XLR Inputs, each with gain and level controls, switchable phantom power, and line/mic switching
- Two stereo line inputs (RCA) with input trim and level control
Intelligent Output and Control
- Master outputs are provided via balanced XLR connectors, with separate left/right controls and a rear-panel mono switch for summed output when needed.
- An independent Aux Output with its own level control allows for zone feeds, submixes, or recording.
- Channel 1 also features a priority override ducker, which attenuates all other inputs by 20 dB when activated?perfect for paging or announcements. A push-to-talk connector is also available on the rear panel.
Built-In EQ and Visual Feedback
- Global 3-band EQ gives you control over overall tonal shaping, with Low (100 Hz), Mid (800 Hz), and High (10 kHz) shelving and bell filters offering ?15 dB of adjustment.
- LED indicators provide visual status for wireless activity, USB connectivity, phantom power, mono output mode, priority override, and power.
Built for Real-World Installations
- Designed for flexibility and dependability in any installation, the MIXXMaker includes universal AC power compatibility (100?120V or 220?240V), a built-in fuse, and a rear-panel voltage selector switch.
- It?s an ideal solution for clubs, gyms, restaurants, paging systems, broadcast submixing, and more.
Additional Features
- Wireless, USB, and minijack inputs
- 2 Balanced XLR mic/line inputs
- 2 stereo RCA line input channels
- Switchable phantom power (+48V)
- Push-to-talk and priority override (Ch. 1)
- Global 3-band EQ (low/mid/high)
- Balanced XLR master outputs with mono switch
- Independent aux output with level control
- LED indicators for mode and status
- 1 RU steel chassis with user-friendly layout
- Universal AC power with voltage selector
Items Included
- ARX MIXXMaker Bluetooth USB Mic/Line Master Mixer
- IEC Power Cord
- Limited 12-Month Manufacturer Warranty (Labor)
- Limited 24-Month Manufacturer Warranty (Parts)
Additional Resources
No additional resources available
ARX MIXXMAKER Specs
Key Specs
| Number of Analog Input Channels |
6
|
| Number of Mic Preamps |
2
|
| Analog Output Channels |
1x Stereo Master Output
1x Mono Aux Send Output |
| Mix Routing |
Main Mix / Aux Send
|
| EQ |
Outputs:
3-Band EQ |
| Built-In Effects |
No
|
| USB I/O |
1x USB-B
|
| Wireless |
Bluetooth
|
| Rack Mountable |
Yes
|
Mixer
| Max I/O Capacity |
6x Input / 3x Output
|
| Number of Analog Input Channels |
6
|
| Number of Mic Preamps |
2
|
| Analog Output Channels |
1x Stereo Master Output
1x Mono Aux Send Output |
| Mix Routing |
Main Mix / Aux Send
|
| Faders & Level Adjustment |
7x Channel Knob
|
| Meters |
Channel Meter:
2-Segment LED Main Meter: 2-Segment LED |
Signal Processing
| Gain/Trim Range |
0 dB to +60 dB
|
| Input Pad |
-20 dB
|
| Dynamic Processing |
No
|
| EQ |
Outputs:
3-Band EQ |
| EQ Parameters |
Master:
Low: ?15 dB at 100 Hz (Shelving) Mid: ?15 dB at 800 Hz (Bell) High: ?15 dB at 10 kHz (Shelving) |
| Graphic EQ |
No
|
| Solo/Mute |
No
|
| Built-In Effects |
No
|
Digital Audio
| Bit Depth |
24-Bit
|
Performance
| Frequency Response |
20 Hz to 20 kHz
|
Connectivity
| Analog Inputs |
2x XLR Input
4x RCA Input 1x 1/8" / 3.5 mm Input |
| Analog Outputs |
3x XLR Output
|
| Phantom Power |
+48 V
|
| Digital I/O |
No
|
| MIDI I/O |
No
|
| USB I/O |
1x USB-B
|
| Wireless |
Bluetooth
|
Compatibility
| OS Compatibility |
macOS / Windows
|
Power
| AC Input Power |
100 to 120 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz |
Physical
| Rack Mountable |
Yes
|
| Rackmount Size |
1 U
|
